| Instrument power supply |
100 - 120VAC ±10%, 47 - 63Hz |
| 220 - 240VAC ±10%, 47 - 63Hz |
| Dimensions |
19" desktop housing (rack mountable), height 330mm (13"), depth 510mm (20") |
| EUT supply |
From an external source, e.g. battery or PA 5840 power amplifier/battery simulator |
| Computer interface |
IEEE 488 (recommended) or RS232 |
| Auxiliary input signals |
DUT FAIL / START-STOP |
| Auxiliary output signals |
CRO-TRIG / TEST-END |
| Input DC voltage range |
60V max. |
| DC current |
100A (250A for 200ms) |
| Switch On/Off time |
2μs |
| Optional Modules |
MT 5510 |
Transient generator ISO pulse 1, 2, 6 and variants
|
| LD 5505 |
Load dump generator |
| FT 5530 |
EFT generator ISO pulse 3a/3b and variants
|
| CDN 500 |
Capacitive coupling clamp |
