EM Test Automotive Transient Emission Set 100 kHz - 125 MHz
- BS 200N100 - Electronic switch, 60V DC/100A: Volt.Drop <1.2V@100A, <0.2V@25A Peak voltage max. 1,000V Reverse-polarity/short-circuit protected
- Volt.Drop <1.2V@100A, <0.2V@25A
- Peak voltage max. 1,000V
EM Test VDS 200N30 Voltage Drop Simulator | 60 V, 30 A
- Voltage up to 60 V
- Current up to 30A
- Bipolar-amplifier models available
PMM L3-100 3-Phase LISN | 9 kHz - 30 MHz, 100 A
- 9 kHz a 30 MHz frequency range
- 100 A max output current
- Large baseplate for optimal grounding
BOLAB 100-TS Series | DC – 200 kHz, 400 W – 18000 W
- DC to 200 kHz full range bandwidth
- Rise time / fall time up to 100 V/µs
- Arbitrary function with 1 Million memory data points
Com-Power LI-4100 LISN | 10 kHz - 10 MHz
- Frequency range of 10 kHz to 10 MHz
- Fully compliant with MIL-STD 461
- 100 Amp(AC) (forced air cooling)
Teseq ISN T8 Impedance Stabilization Network
EM Test UCS 200N Automotive Transient Generator for ISO 7637
- Built-in EFT/Burst generator module
- Built-in Micropulse generator module (ISO 7637, JASO, SAE and NISSAN)
- Built-in coupling network 60V, up to 200A
Com-Power LI-125A Line Impedance Stabilization Network 150 kHz - 30 MHz
- “Air-core” inductors to prevent saturation
- Specification: CISPR 16-1-2 / ANSI C63.4
- Application: Power Line conducted emission tests
EMCO/ETS-Lindgren 3825/2 Line Impedance Stabilization Network
PMM L3-64 3-phase LISN | 9 kHz - 30 MHz, 63 A
- 9 kHz a 30 MHz frequency range
- 63 A max output current
- Large baseplate for optimal grounding
Hilo-Test CAR-AWG 6000 Battery Simulator
- Batterie simulator
- Bandwidth DC-200kHz
- Signal Bandwith DC-1MHz (small signal -3dB)
Teseq PA 5740 Power Amplifier/Battery Simulator
- Capacitive stability mode
- High bandwidth up to 180 kHz
- Fast slew rate
Com-Power LI-325 Line Impedance Stabilization Network
Com-Power LI-1100 Line Impedance Stabilization Network
- Frequency range of 150 kHz to 30 MHz
- 100 Amp (AC) (forced air cooling)
- Fully compliant with CISPR 16-1-2 / ANSI C63.4
Solar 7225-1 Line Impedance Stabilization Network (1 GHz LISN)
- Line impedance stabilization network
- Supports up to 200 amperes in 50 H styles and 500 amperes in 5 H styles
- Frequency range of 10 kHz – 400 MHz (useable up to 1 GHz)
EM Test LD 200N100 Load Dump Generator
- Built-in 100A coupler 60 V/100 A
- Built-in battery switch for 100A
- Generates Clipped Load Dump pulses
EMCO / ETS-Lindgren 3810/2 Line Impedance Stabilization Network
- Frequency Range: 9 kHz - 30 MHz
- Continuous Current Rating: 10 A
- Earth Line Choke
Teseq NSG 5600 Automotive Transient Generator
EM Test RCB 200N1 Transient Immunity Test Generator for FORD EMC-CS-2009.1
- Approved by Ford acc. to EMC-CS-2009.1 requirements
- Pulses CI 220: A1, A2-1, A2-2, C-1 and C-2
- Pulse CI 260: F
Bolab AN-ABCD-60 Artificial Network System | 1000 V, 60 A
- In accordance with LV123, ISO 21498, MBN 11123, VW 80300, and IEC 61851-23
- Liquid cooled for stable resistance temperature and constant ohmic value
- True continues current loading without derating, ideal for in-the-loop testing during the development stage of HV components
EM Test PFM 200N100.1 Automotive Power Fail Simulator
- Switch for Power supply (100 A) and signal/data lines (2 A)
- Pulses E10 and E13 of the LV 124/LV 148 standard
- Bidirectional current direction
Fischer Custom Communications LISN 50-100-1
BOLAB Systems BLS-130-70N-TS 4-Quadrant Voltage Amplifier
- DC to 200 kHz full range bandwidth
- DC up to 1 MHz (small signal -3 dB)
- Option for running as a current amplifier
Teseq NSG 5500 Automotive Transient Immunity Tester for ISO 7637
PMM L3-500 3-Phase LISN | 9 kHz - 30 MHz, 500 A
- 9 kHz to 30 MHz frequency range
- Up to 300 A (continuous); 500 A (20 min.) rated output current
- Suitable for DC to 60 Hz power lines
