PMM 1008 Magnetic Field Generator | 50/60 Hz, 1200 A/m
- Programmable 1200 A current generator with output feedback
- Standard, custom and ramp tests
- Autocalibration
Haefely / Bellcore 1089 Lightning Test System
- Full hybrid waveforms according to the lastest GR-1089 Core section 4
- 1st and 2nd level lightning surges
- Integrated automatic coupling for 2 and 4 wire telecom system
Teseq NSG 3150 Combination Wave Surge Generator | 15 kV
- Surge voltage up to 15 kV
- CDN range: Single & Three Phase, up to 63 A, 690 VAC, 1000 VDC
- Safest 15 kV connector type on the market
Thermo Keytek 424 Surge Generator/Monitor
- Peak voltage and current values measured at the load
- Clean waveforms
- Remote programmable/readout operation
Thermo Keytek 587+ w/ S3/S21 plug-ins Surge Generator
Haefely AXOS 8 Compact Conducted Immunity Test System
- Easy to operate with manual and automated test modes, software assisted test preparation, pre-defined test routines and visual aided test setups.
- Economic & Efficient Touch screen guarantees reduction of time and effort - Experience and know-how at a reasonable price.
- Safe and reliable operation by using safety interlock, warning lamp and emergency stop functions.
Haefely AXOS5 Compact Immunity Test System
- Easy to operate with manual and automated test modes, software assisted test preparation
- Pre-defined test routines and visual aided test setups
- Economic & efficient touch screen guarantees reduction of time and effort
Teseq Best Plus EMC Conducted Immunity Test System
- Pulse Form: 5/50 ns
- Pulse Amplitude: 200 - 2200 V
- Pulse Frequency: 1 - 100 kHz
Teseq CAS3025 Burst/EFT Pulse Verification Kit
- Verification/calibration kit for IEC/EN 61000-4-4, amendment 2
- For peak voltages up to 8.8 kV
- INA 265B: 50 Ω termination
Schloder CDG7000 Conducted Disturbances Test System
- Compact device
- Consists of an RF signal generator, an RF-power amplifier, a 3-channel RF voltmeter, and a directional coupler
- RF power amplifier is available in three different models
Teseq CDN 3063-S100 3-Phase Coupling/Decoupling Network
- Three phase models with broad current range up to 100 A
- Fully automated surge and/or burst coupling
- IEC and ANSI coupling methods
Teseq CDN 3083-B100 EFT/Burst Coupling/Decoupling Network
- Permits test pulses of up to 8.8 kV
- Designed to be used with an EUT supply
- 3-phase burst pulse coupling network
Teseq CDN3063-C32 Coupling/Decoupling Network
- 3-phase models with broad current range
- Fully automated surge and burst coupling
- IEC and ANSI coupling methods
Teseq CDN 3425 Burst/EFT Coupling Clamp
- With Safety Cover or Interlock
- New design
- Complies with IEC 61000-4-4 Ed 2.0 2004
Thermo Keytek CEMaster EMC/EMI Immunity Test Simulator
EMC Partner CN-EFT1000 Capacitive EFT/Burst Coupling Clamp
- Capacitive EFT/burst coupling clamp
- Complies with IEC 61000-4-4 EFT, IEC 61000-4-18, and ANSI C37.90.1 standards
- Used with the MIG Series
EM Test CNV 504N7.3 Coupling/Decoupling Network
- CDNs according to IEC/EN 61000-4-5 and IEC/EN 61000-4-12
- Surge coupling by gas arrestor or 0.5µF capacitor, ringwave by 3.3µF capacitor
- 20mH decoupling inductor per line
EM Test CSS 500N10 Surge Current Generator, 6 kV, 10 kA
- Wave Shape 8us/20us
- Output voltage (open circuit): 250V to 6,000V +/-10%, Step width 50V
- 250V to 6,000V +/-10%,
Compliance West MegaPulse D5-PF Defibrillation Proof Tester
- Direct Joules readout on front panel after Energy Reduction Test.
- Increased accuracy in accordance with IEC 60601-2-25 and -2-27:2011 requirements.
- 20 second period between pulse delivery,
Haefely DIP 116 Automatic Dip Transformer | 16 A, 264 V
- 7" / 800 x 480 / 24 bit touchscreen
- Reduction of daily working effort due to easy access menu structure
- Intuitive menu prompting
EMC Partner DOW-CG1 Damped Oscillatory Wave Generator
- External data line coupler
- Supports magnetic field testing
- Phase angle synchronization
EMC Partner DOW-CG1-S-F-I Slow/Fast Damped Oscillatory Wave Generator
- 7” color touchscreen
- High performance built-in CDN
- EUT overcurrent protection
EMC Partner DOW3000 Oscillatory Wave Generator
- Slow wave, fast wave or impulse voltage testing or any combination
- Integrated 32 A three-phase coupler
- Oscillatory wave of 100 kHz to 30 MHz
Thermo Keytek ECAT E103 Control Center
- Virtual Front Panel™ retains key operating parameters during set up & testing
- Multi-level system interlock architecture provides maximum safety
- Single output port/instant mode switching
Thermo Keytek ECAT E411 EFT/Noise Burst Simulator
- All test parameters under full software control via KeyTek BurstWare
- Burst Voltages from 200V to 4.4kV
- IEC specified 5ns/50ns impulses
Thermo Keytek E420 EFT Burst Simulator Unidirectional Impulse Wave
Thermo Keytek ECAT E4551kV Surge & EFT Coupler/Decoupler
- Single phase
- 480V rms Volatage
- 16A Current
Thermo Keytek ECAT E4553kV Surge & EFT Coupler/Decoupler
- 3-phase
- 480V rms Volatage
- 16A Current
Thermo Keytek ECAT E506-4W 2/10μs Telecom Surge Simulator
- 2/10 μs, 50-800 V, 100 A/terminal with 800 V open-circuit voltage
- 2/10 μs, 50-1500 V, 100 A/terminal with 1500 V open-circuit voltage
- 2/10 μs, 100-2500 V, 500 A/terminal with 2500 V open-circuit voltage
Thermo Keytek ECAT E509A Surge Simulator for Bellcore GR-1089
Thermo Keytek ECAT E510A 10 kV Combo Wave Surge Simulator
Thermo Keytek ECAT E513 Surge Simulator for Voltage Ramps
- Controlled Open-Circuit Voltage Ramps of: 0.1kV/μs, 0.5kV/μs, 1.0kV/μs, 5.0kV/μs, 10kV/μs
- Open-Circuit Voltage: to 3kV peak
- Short-Circuit Current: to 50A peak
Thermo Keytek ECAT E571 Telecom Coupler/Decoupler
Thermo Keytek ECAT Computer-Aided EMI Immunity Test System
- Tests for pulsed EMI hazards: EFT, Surge, PQF
- Ideal test system to address most applicable EMC & Telecom standards, including CE Mark/IEC standards
- Easy-to-use Windows-based application software for quick implementation of international & national test routines
Thermo Keytek ECAT E521
- Tests for pulsed EMI hazards: EFT, Surge, PQF
- Ideal test system to address most applicable EMC & Telecom standards, including CE Mark/IEC standards
- Easy-to-use Windows-based application software for quick implementation of international & national test routines
Thermo Keytek ECAT E522
- Tests for pulsed EMI hazards: EFT, Surge, PQF
- Ideal test system to address most applicable EMC & Telecom standards, including CE Mark/IEC standards
- Easy-to-use Windows-based application software for quick implementation of international & national test routines
Haefely ECOMPACT4 Compact Transient Immunity Tester
- Up to 6 complete EMC immunity standards in a single test station, including: IEC / EN 61000-4-4 Ed. 2 Electrical Fast Transient IEC / EN 61000-4-5 Surge Combination Wave IEC / EN
- IEC / EN 61000-4-4 Ed. 2 Electrical Fast Transient
- IEC / EN 61000-4-5 Surge Combination Wave
Haefely ECOUPLER4 Three-Phase Coupling / Decoupling Network
- Two different test impulses
- Combination wave 1.2/50us - 8/20us up to 4.2kV
- Burst 5/50ns up to 4.2kV
EM Test EFT 500N5.5 Electrical Fast Trasient/Burst Immunity Test Generator, 4,8kV, 1MHz
- 1-phase coupler, 250V/32A
- Test Level Voltage range: 200V - 4,800V Into 50ohm: 100V - 2,400V Pulse shape: Into 50ohm load Rise time tr: 5ns ± 30% Pulse width td: 50ns ± 30% Pulse shape: Into
- Voltage range: 200V - 4,800V
EM Test EFT 500N8.1 EFT/Burst Generator, 7kV, 1MHz
- 3-phase coupler; 3 x 440V/32A
- Test Level Voltage range: 1,000V - 7,000V Into 50ohm: 500V - 3,500V Pulse shape: 5/50ns into 50ohm load Rise time tr: 5ns ± 30% Pulse width td: 50ns ± 30% Pulse
- Voltage range: 1,000V - 7,000V
M Precision Laboratories EMC Pro Advanced EMC Test System
M Precision Laboratories EMCPro PLUS EMC Test System
- Portable, mid-range EMC test system
- Resident capabilities for compliance testing to 6 IEC/EN standards
- Addresses ANSI/IEEE C62.41, ITU, ETSI, & UL 864 standards
Pacific Power EPTS-100A-3 Electronic Power Transfer Switch
- AC Voltage Dips, Interruptions and Variations
- Available in Single or Three Phase Three versions
- Requires second AC Source or AC Line for Nominal Voltage
Pacific Power EPTS-32A-3 Electronic Power Transfer Switch
- AC Voltage Dips, Interruptions and Variations
- Available in Single or Three Phase Three versions
- Requires second AC Source or AC Line for Nominal Voltage
Noiseken FNS-AXII EFT Generator
- 5-inch LCD
- Continuous, Frequency Modulation, and Polarity Reversal modes
- For testing single and three phase EUTs
Montena GP20-01-2 High Speed Pulse Generator 20kV, 400A
Schwarzbeck HHS 5204-36
- No calibration required
- High temperature proof Teflon wire packet
- Capable of generatic magnetic fields up to 3000 A/m (for a short time)
Schwarzbeck HHS 5206-132
- Generates magnetic fields according to MIL-STF-461F applications
- Used to calibrate magnetic field probes or sensors
Schwarzbeck HHS 5206-25
- High temperature proof Teflon-coated wire packet
- Magnetic field generation up to 2700 A/m for a short time
- Used to calibrate magnetic field probes or sensors
EFT/Burst Testing System: 5.5kV, 3 Phase AC, 100A
Compliance West MegaPulse Implantable Test 1 Surge Tester
- 140V and 380V test voltages.
- Front panel voltage meter indicates test peak open circuit voltage and polarity.
- Output voltage and polarity are controlled manually from the front panel.
Compliance West MegaPulse Implantable Test 2 Surge Tester
- Biphasic and monophasic, 140V and 270V peak test voltages in accordance with Standard requirements.
- Front panel voltage meter indicates test peak open circuit voltage and polarity.
- Output voltage and polarity are controlled manually from the front panel.
EMC Partner IMU-MGE Conducted Immunity Test System
- One touch parameter editing in run state
- Impulse stability over long periods
- Intuitive multi touch graphical interface
EMC Partner IMU-MGS Conducted Immunity Generator
- One touch parameter editing in run state
- Impulse stability over long periods
- Intuitive multi touch graphical interface
EMC Partner IMU3000 Immunity Tester
- 7” Colour touch panel
- Rotary knob for navigation and data entry
- EPOS (EMC PARTNER Operating System) a new concept in graphical user interface
EMC Partner IMU4000 Immunity Tester 4kV
Teseq INA6501 Manual Step Transformer
- Integrated function unit to Modula system
- Power line dips to 0%, 40%, 70% and 80%
- Complies with IEC/EN 61000-4-11
Teseq INA 6502 16 A Programmable Step Transformer
- Integrated function unit to Modula system
- Power line dips to 0%, 40%, 70%, and 80%
- Complies with EN/IEC 61000-4-11
Teseq INA 702 Magnetic Field Coil | 1200 A/m Pulsed
- 11 turns with tap off at turn 1,5,11
- Includes stand with socket, rotation mechanism with brake, vertical positioning mechanism, traceable calibration certificate, 2 termination plugs (Pulse and power), cable for connecting to MFO 6501
- Can be used with NSG 1007 sources and INA 2141 (impedance box for Magnetic Field tests) by use of optional adapter cable.
Noiseken INS-4001 Impulse Noise Generator
- Generated pulses of less than 1ns rise time up to 2kV or 4kV
- Selectable pulse widths from 50ns to 1000ns at a step of 50ns, 10ns available as the shortest width.
- Easily selectable coupling modes to EUT power lines
Noiseken INS-4020 Noise Simulator
- Automatic ramp operation for output voltage, phase angle and repetition period
- Floating output
- Coupling mode selection by plugging the supplied coaxial connector to the selected port
NoiseKen INS-4040 Impulse Noise Simulator
- Automatic ramp operation for output voltage, phase angle and repetition period
- Floating output
- Coupling mode selection by plugging the supplied coaxial connector to the selected port
Noiseken INS-420 Impulse Noise Generator
- Two kinds of wave, square and triangular (standard) can be selected .
- Even one-shot pulse can be mounted on the optional phase angle of the power supply line.
- All operation can be made on the front panel, making handling very easy.
Noiseken INS-AX2-420 Impulse Noise Simulator
- Realize automation and efficiency in the test
- Rich variety is prepared along output voltage and EUT power capacity
- Simple and easy setting of the pulse widths with preset of 8 kinds pulse widths
Haefely IP4A Capacitive Coupling Clamp
- Maximum cable size 40mm
- Minimum test cable length 1m
- Maximum EFT voltage 8kV
Haefely IP4B Capacitive Coupling Clamp
- Designed as per IEC 61000-4-4 Edition 3
- EFT/Burst testing of signal and data lines
- For cable diameter from 4 – 40 mm
Haefely IP6.2 Manual Surge Coupling Unit
- 4 wire integrated unit
- Coupling CWG surges
- Coupling 10/700 surges
Powerside IPC-480V-200A Industrial Power Corruptor
- High power handling up to 480 Vrms nominal, 200 amps continuous
- Creates voltage sags and swells, from 0% to 125% of nominal, from 1 cycle to 30 seconds
- Creates voltage sags and swells, from 0% to 125% of nominal, from 1 cycle to 30 seconds
Noiseken LSS-6230 Lightning Surge Simulator
- Lightning Surge Simulator
- Conforming to IEC61000-4-5 ed2 Standard
- Ring wave conforming to ANSI/IEEE C62.45 available
Noiseken LSS-710B Lightning Surge Simulator
Noiseken LSS-720B Lightning Surge Simulator
- Voltage surge test (1.2/50µs) and current surge test (8.2µs) specified under JEC-210 and 212 standard. (JEC: Japanese Electrotechnical Committee)
- High voltage surge test up to 20kV or 30kV and high current surge test up to 4000A or 6000A
- Built-in 2-state isolation transformers.
Noiseken LSS-F02 Series Lightning Surge Simulator
- Conforms to the IEC61000-4-5 standard
- "Output voltage 15kV, current 7500A" which can conduct breakdown resistibility test
- "50% reduction of the output interval" which can drastically reduce the test time
Haefely MAG 100 Magnetic Field Generator for IEC 61000-4-8
- Up to 110A/m field strength
- Different coil sizes available
- Exactly as defined in IEC 1000-4-8
Haefely MAG 1000 Magnetic Field Generator | 50/60 Hz, 1100 A/m
- Continuous and short duration testing exactly as it specifies in IEC 61000-4-8
- No external power supplies needed
- Up to 1100A/m field strength
EMC Partner MF1000-1 Inductive Coil | 50/60 Hz, 1855 A/m Pulsed
Teseq MFO 6502 Automatic Power Line Frequency Magnetic Field Generator | 50/60 Hz, 40 A/m
- Integrated function unit to NSG 3040
- Magnetic field test with 50 or 60 Hz up to 40 A/m
Haefely MFS 100 Frequency Pulse Magnetic Field Test System
- Up to 1200A/m field strength for pulse magnetic field.
- Up to 100A/m field strength for frequency magnetic field.
- Standard coil designed for major application as defined in the IEC document.
Teseq Modula ESD Test System
Haefely MSURGE Antenna for a Magnetic Impulse Field Test System
- Up to 3000A/m field strength
- Standard coil designed for major application as defined in the IEC document
- Sturdy construction
Haefely MSURGE-A Pulse Magnetic Field
- Plug-and-play capability with the AXOS series test unit
- Automatically controlled test routines via AXOS unit
- Includes 1m x 1m coil for magnetic field generation
Teseq NSG 3040A Multifunction Generator, 4.8 kV
- One box solution system
- Surge voltage to 4.8 kV
- EFT/Burst to 4.8 kV / 1 MHz
Teseq NSG 3060A Multifunction Generator | 6.6 kV
- One box solution system
- Surge voltage to 6.6 kV
- Ringwave voltage to 6.6 kV
Teseq NSG 4031 Broadband Immunity Test System
- IEC/EN 61000-4-31 immunity test system
- 150kHz to 80MHz integrated white noise generator
- 3 power meter inputs - 9kHz to 1GHz
Teseq NSG 1003 Mains Drop - Out Simulator
- Tests as per IEC 61000-4-11, EN 61000-4-11, etc
- Local operation with large display panel
- Peak currents up to 500A
Teseq NSG1025 Fast Transient Burst Generator
- Conforms to IEC 801-4; IEC 1000-4-4
- Test voltages up to 4400V
- Burst frequencies up to 10KHz
Teseq (Schaffner) NSG2025 Fast Transient/Burst Generator
Teseq (Schaffner) NSG 2200-3 3 Phase AC Switch
Teseq NSG 3025 Burst Generator
- Compact, full-capability instrument
- For standard tests to EN 61000-4-4, IEC 1000-4-4, etc.
- Handles tests to product standards and company standards
Teseq NSG 3040 Transient Generator
- Modular, expandable system
- Surge voltage to 4.4 kV
- EFT/Burst to 4.8 kV / 1 MHz
Teseq NSG 3040-SOW Slow Oscillating Waveform Generator
- Fulfills requirements for IEC/EN 61000-4-18 & ANSI C37.90.1
- Oscillation frequency range of 100 kHz to 1 MHz
- Generates 0.2 to 4.4 kV of power
Teseq NSG 3060 Transient Generator
- Modular, expandable system
- Surge voltage to 6.6 kV for overtesting
- Easy to use 7" color touch screen
Teseq NSG 560 High Energy Pulse Generator
- Conforms to VDE 0160, ANSI C62.41 (1991), EN 50178, DIN VDE 0160 or EN50178: Safety requirements for electronic equipment for use in electrical power installations and their assembly into electrical
- Test voltages of up to 800 V
- Internal pulse shaping
Teseq NSG600 Interference Simulator System
- Dropout, Sag and Swell Simulations
- Power to a device being tested can be either fully interrupted or made to deviate from the normal value
- Connection for future expansion to 3 phase dropouts using NSG633
EM Test NX5 Multifunctional Test Generator
- Small transient generator with 7" color touch screen
- IEC 61000-4-4 | Burst testing, 5.5kV
- IEC 61000-4-5 | Surge testing, 5.0kV
EM Test NX7 Multifunctional Test Generator
- Compact generator featuring 7" color touch screen
- IEC 61000-4-4 | EFT/Burst testing, 5.5 kV
- IEC 61000-4-5 | Surge wave/combination wave testing, 7.0 kV
EM Test OCS 500N6 Oscillatory Wave Simulator
- Standalone test generator
- Includes Ringwave up to 6kV
- Includes Damped Oscillator Waves up to 3kV
EM Test OCS 500N6F | 3 MHz / 10 MHz / 30 MHz
- Fully automated single box test system
- Single DUT port
- Fast Damped Oscillatory Waves up to 4.4kV
Haefely PCD 100 Single Phase CDN for PSURGE 8000 Platform
- Maximum impulse voltage: 7.5kV
- Maximum AC voltage: 240VRMS
- Maximum DC voltage: 110V
Haefely PCD120 4 Wire CDN for 10/700µs Surge Generator
- Impulse voltage up to 7.4kV
- 15 and 40ohms switchable impedance
- Oscilloscope Impulse monitors
Haefely PCD 150 4 Wire Manual CDN for 100kHz/1MHz Ring/Damped Oscillatory Wave
- Damped oscillatory wave 100kHz and 1MHz
- Ring Wave 100kHz with Z=200 ohms
- Up to 4 wires can be tested with a single unit
Haefely PEFT 4010 EFT / Burst Generator for IEC / EN 61000-4-4
- Impulse voltage up to 4,800V
- Spike frequency 1Hz to 2MHz
- 5 burst modes
Haefely PEFT 8010 Burst Test System
- EFT impulse generation according to newest standards and latest technology.
- ESD control and report functions for attaching an Electrostatic Discharge gun.
- Automatic test operation for shortest measuring time and minimal setup effort.
Haefely PEFT Junior Burst Tester
- EUT surveillance (failure detection)
- Automatic test report generation
- Automatic output performance verification of the PEFT Junior in accordance with the provisions of the IEC Standard
Haefely PIM 100 Combination Wave Impulse Module
Haefely PIM 110 Ring Wave Impulse Module
- Floating high voltage output
- Ring wave 0.5us - 100kHz (voltage & current)
- 7.8kV impulse voltage
Haefely PIM 120 7.4kV Telecom Module for IEC 61000-4-5 Data Lines
- 10/700us impulse shape up to 7.4kV
- according to ITU K.44
- Fully automatic coupling network
Haefely PIM 150 Oscillating Wave Module for IEC 61000-4-12 & ANSI C37.90.1
- 100 kHz & 1 MHz frequencies
- 75 ns rise-time
- 3.3 kV impulse voltage
Haefely PIM 155 Oscillating Magnetic Field Module | 100 kHz & 1 MHz for IEC 61000-4-10
- 100 kHz & 1 MHz frequencies
- Up to 100 A/m magnetic field strength
- Variable burst duration
Haefely PIM 200 Current Impulse Module
- 8/20μs current impulse from 800A up to 12kA
- 10/1000μs current impulse from 8A up to 110A
- Integrated test cabinet
Haefely PIM 800 / PIM 810 / PCD 800 Telecom Surge System for TIA-968-A (FCC part 68)
- Full hybrid waveforms according to the latest issue of TIA-968-A
- Telecom line surges type A and B
- Power line surges
Haefely PLINE 1610 Voltage / Interruption Tester for IEC 61000-4-11
- Totally reproducible test results
- Fully automated, time saving design
- Integration in a full EMC test system
Teseq PNW 2051 Impulse Network for NSG 2050
- Pulse Form: 0.5/700 µs (open-circuit) 10/700 µs (short-circuit)
- 0.5/700 µs (open-circuit)
- 10/700 µs (short-circuit)
Teseq PNW 2056 Impulse Network, Oscillatory Waves
Haefely PS 1500 Impulse Voltage Generator, 15 kV
- Impulse counter
- Repetition up to 24 pulses / minute
- External trigger input
Powerside PSL-IPC-240V-25A Industrial Power Corruptor
- High power handling up to 240Vrms nominal, 50 amps continuous
- Creates voltage sags and swells, from 0% to 125% of nominal, from 1 cycle to 30 seconds
- Creates voltage sags and swells, from 0% to 125% of nominal, from 1 cycle to 30 seconds
Haefely PSURGE 30.2 Surge Test System | 30 kV / 30 kA
- Up to 30 kV impulse voltage
- Up to 30 kA impulse current
- automatic polarity switching
Haefely PSURGE 4.1 0-4kV AC Surge Generator
Haefely PSURGE 4010 4kV Combination Wave Surge Generator
- Combination wave Voltage: 1,2/50us Current: 8/20us
- Impulse voltage: 200V ... 4.2kV
- Impulse current: 100A ... 2,1kA
Haefely PSURGE 6.1 Surge Tester
Haefely PSURGE 8000 Surge Platform Test System
- Built according to IEC/EN 61000-4-5 Ed. 1 & 2 and ANSI C62.41/45
- 1.2/50 µs open circuit up to 7.4 kV
- 8/20 µs short circuit up to 3.7 kA
Com-Power SG-168 Surge Generator
- Surge generator
- High voltage protection
- Type A, Type B, and Power Line surge tests
EMC Partner SRC16-1P Single Phase Dip Transformer
- Single phase dip transformer
- Designed to perform dips tests according to IEC 61000-4-11
- Accessory used with the EMC Partner IMU3000 or EMC Partner IMU4000
EMC Partner TEMA3000 Software Test Suite
- Drag and drop technology
- Test setup libraries
- Color graphic user interface
EMC Partner TRA2000 Transient Test System
- 4kV surge levels
- Internal motor variac
- All parameters on one screen
EMC Partner TRA3000 Transient Test System
- Modular design, user configurable
- Environmentally friendly
- Humidity, pressure and temperature sensor measure lab environment
EM Test TSS 500N10 Telecom Surge Generator for Belcore/Telcordia GR-1089
- Standalone tester for 10/700us pulse as per EN/IEC 61000-4-5
- Test voltage up to 10kV
- Complies to ITU-T for enhanced level testing
Haefely TW 8 Telecom Wave Impulse Module 10/700 µs (for operation with AXOS8 only)
- 2 pairs of communication lines or 4 lines individually
- Automatically controlled by AXOS8
- Predefined according norm and individual setups available
EM Test UCS 500 M6A Modular Ultra Compact Simulator
EM Test UCS 500N5.2 Ultra Compact Simulator
- Burst module (IEC/EN 61000-4-4) up to 5.5kV
- Surge module (IEC/EN 61000-4-5) up to 5kV
- PowerFail module (IEC/EN 61000-4-11)
EM Test UCS 500N5E EFT/Burst Generator, 5.5kV
- Test voltage: 200V - 5,500V ± 10%; 100V - 2,750V ± 10% into 50ohm
- 200V - 5,500V ± 10%;
- 100V - 2,750V ± 10% into 50ohm
EM Test UCS 500N5V 5kV Combination Wave (Surge) Generator
- Voltage (o.c.): 160V - 5,000V ± 10%
- Pulse front time: 1.2us ± 30%
- Time to half value: 50us ± 20%
EM Test UCS 500M4 Ultra Compact Simulator
EM Test UCS 500N5 Multifunctional EFT, Surge & Power Fail Generator
- Burst module (IEC/EN 61000-4-4) up to 5.5kV
- Surge module (IEC/EN 61000-4-5) up to 5kV
- TSurge module (IEC/EN 61000-4-5); optional
EMC Partner VAR-EXT1000 External 16 A Variac
- Works with all generators of the IMU or TRA Series
- Automated variac control from generator
- Can also be used with AC magnetic field antenna
EM Test VCS 500N10 Combination Wave Simulator
- Surge pulses up to 10kV/5kA
- Single phase or three-phase coupler up to 100A (external options)
- Fail inputs
EM Test VCS 500N8.5 8kV Combo Wave/Surge Generator
- Output Direct: Via HV connectors for external coupling networks (Zi = 2ohm with optional adapter IMN 2) Coupling mode: Line to line with 2ohm; Line(s) to PE with 12ohm 3 x 440VAC / 32A;
- Direct: Via HV connectors for external coupling networks (Zi = 2ohm with optional adapter IMN 2)
- Coupling mode: Line to line with 2ohm; Line(s) to PE with 12ohm
EM Test VSS 500N10 Voltage Surge Simulator, 10 kV for UL 6500
- Voltage (o.c.): 500V - 10,000V ± 10%
- Surge capacitor: 1nF
- Series resistor: 1,000ohm
EM Test VSS 500N10.3 1.2/50us Surge Generator for Solar Panel Tests
- Surge voltage up to 10kV
- Generator designed to comply with UL 1703
- 7 different capacitance ranges selectable from 30nF to 180nF
EM Test VSS 500N15.1 Voltage Surge Simulator
- Test pulse 1.2/50μs up to 15kV as per EN/IEC 60255-5
- 7 different test levels
- Source impedance 500 ohm
EM Test VSURGE NX20
- Surge voltage up to 20 kV
- 11 different capacitance ranges selectable from 20 nF to 170 nF
- Compliant to IEC/EN 61730-1/2
Haefely VTM 15000 Impulse Transformer for Insulation Testing
- 1.2/50us voltage impulse
- Output amplitude up to 15kV
- Source impedances 12 Ohm, 40 Ohm and 500 Ohm
Haefely VTM 15000/05 Impulse Transformer For Isolation Testing
- 1.2/50μs voltage impulse
- Output amplitude up to 15kV (PSURGE 8000 & PIM 100)
- Output amplitude up to 14kV (AXOS 8)
