Teseq ISN T8 Impedance Stabilization Network

The Teseq ISN-T8 offers exacting impedance stabilization to ensure the most accurate EMC testing results. The design caters to a wide array of testing scenarios, offering unmatched flexibility to accommodate a multitude of applications. The ISN T8 is meticulously engineered to facilitate measurements on as many as four unshielded single balanced pairs, as delineated in section D.3. It features a high longitudinal conversion loss (LCL), rendering it suitable for application with one to four unscreened balanced pairs. Built with a commitment to quality, the ISN-T8 promises enduring durability, guaranteeing a product that you can rely on for years.

Product Info

Frequency range:	150 kHz to 30 MHz
Line parameters:	1 up to 4 pair(s)
Power rating (EUT- and AE Port)
AC max. voltage (line to ground):	63 V
DC max. voltage (line to ground):	100 V
Current max :	400 mA (line), 800 mA (pair)
Test voltage:	200 VDC, 2 sec
Common mode impedance (EUT Port) 150 kHz to 30 MHz:	150 Ω ±20 Ω
Phase angle (EUT Port) 150 kHz to 30 MHz:	0° ±20°
Coupling path (In/Out-port/EUT)
Connection:	BNC 50 Ω
RF voltage:	<15 V
Frequency range:	150 kHz to 30 MHz
Voltage division factor (RF input to EUT port) 150 kHz to 30 MHz:	10 dB ±1 dB
Transmission bandwidth (wanted signal) EUT/AE B3 dB:	> 100 MHz sin

For use with one, two, three, or four unscreened balanced pairs
CISPR 22, Ed.5.2, 2006 and EN 55022 Sept. 2006 (IEC/CISPR 22: 2005 modified) for Cat.3 and Cat.5
1000BaseT and PoE application
Changeable pin-arrangements with RJ11 and RJ45
