Keysight PV8922A Photovoltaic Array Simulator

The Keysight PV8922A Photovoltaic Array Simulator is engineered for solar industry applications, providing precise simulation of photovoltaic (PV) array behavior under various environmental conditions. Enabling users to accurately evaluate the performance and efficiency of solar inverters and other PV equipment, the PV8922A offers realistic testing environments for dynamic response analysis, including maximum power point tracking (MPPT) and inverter efficiency. This simulator delivers up to 20kW DC, with a max output DC voltage of 2000 VDC, and an input voltage of 400/480 VAC. The PV8922 features programmable profiles for customized testing sequences, essential for grid compliance testing and product development. The PV8922A allows users to swiftly simulate I-V curve properties under environmental conditions from temperature to irradiance and cell technology, enhancing productivity and reliability in solar technology applications.

Product Info

Max Voltage	2000 V
Current @ Max Voltage	10 A
Voltage @ Max Current	666 V
Max Current	30 A
Max Power	20 kW
AC Input Voltage (VAC)	400/480 VAC
Output Voltage Ripple and Noise	CV p-p: 3 V CV rms: 400 mV
Load Regulation	Voltage: 100 mV Current: 4 mA
Programming and Measurement Accuracy	Voltage: 0.04%+150 mV Current: 0.03%+3 mA
Transient Response	Recovery Time: 300 µs Settling Band: 20 V

Maximum Power: 20 kW DC
Maximum Output DC Voltage: 2000 VDC
Input Voltage: 400/480 VAC
I/V Curve Specification: Curve Mode or Table Mode
Also, functions as traditional autoranging DC power supply
