Teseq CN Series Coupling Network (CN) For IEC / EN 61000-4-16, DC to 150 kHz

The Teseq CN Series Coupling Network (CN) is designed for IEC / EN 61000-4-16, DC to 150 kHz. Each coupling network is related to the type of cable and connector; a specific 60 dB decoupling network is required in addition to the coupling network type M and AF. Teseq CN Series coupling networks feature an M series for DC or AC power ports, A series for communication ports intended for unscreened, unbalanced lines, and a T series for unscreened balanced pairs. 4 mm banana sockets are included for M and A series, as well as a terminal block for M type with 100 Amps and RJ45 sockets for T series.

Product Info Related Products

Teseq CN Series Part #	Description
255600	CN M232-DC Coupling network accord. IEC 61000-4-16, M2, 32 A, DC
257050	CN M232-300-DC Coupling network accord. IEC 61000-4-16, M2, 32 A, 300 V DC
255601	CN M232-AC Coupling network accord. IEC 61000-4-16, M2, 32 A, AC
255602	CN M332-AC Coupling network accord. IEC 61000-4-16, M3, 32 A, AC
255615	CN M432-AC Coupling network accord. IEC 61000-4-16, M4, 32 A, AC
258000	CN M4100-AC Coupling network accord. IEC 61000-4-16, M4, 100 A, 690 V AC
255614	CN M432-3LN-AC Coupling network accord. IEC 61000-4-16, M4, 3xL,N (without PE line) 32 A, AC
255613	CN M532-AC Coupling network accord. IEC 61000-4-16, M5, 32 A, AC
255603	CN A201-R Coupling network accord. IEC 61000-4-16, AF2, 16 A, DC / AC, remote switch
255604	CN A201-M Coupling network accord. IEC 61000-4-16, AF2, 16 A, DC / AC, manual switch
255605	CN A401-R Coupling network accord. IEC 61000-4-16, AF4, 16 A, DC / AC, remote switch
255606	CN A401-M Coupling network accord. IEC 61000-4-16, AF4, 16 A, DC / AC, manual switch
255607	CN T8-AC Coupling network accord. IEC 61000-4-16, T8, 1000BaseT, AC
255608	CN T8-DC Coupling network accord. IEC 61000-4-16, T8, 1000BaseT, DC
255609	CN T444-AC Coupling network accord. IEC 61000-4-16, T4, 10 / 100BaseT, AC
255610	CN T444-DC Coupling network accord. IEC 61000-4-16, T4, 10 / 100BaseT, DC
97-255600	CN-TC Traceable calibration (ISO17025) for IEC 61000-4-16 requirements, order only with CN

M4, 100 A, 690VAC
Coupling networks designed for IEC / EN 61000-4-16
M series for DC or AC power ports A series for communication ports, intended for unscreened, unbalanced lines
T series for unscreened balanced pairs
4 mm banana sockets for M and A series
Terminal block for M type with 100 Amps
RJ45 sockets for T series
