Solartron SI 1287A Potentiostat & Galvanostat

The Solartron SI 1287 Potentiostat and Galvanostat is part of the 12xx Family series. This device is also an electromedical interface to be used with RF analyzers. The Solartron SI 1287 Potentiostat and Galvanostat is a comprehensive and accurate device with impressive measurement resolution and simultaneous voltage and current measurement capabilities.

What Is The Solartron SI 1287 Potentiostat & Galvanostat Used For?

DC tests and AC impedance tests can be completed with ease with the Solartron SI 1287. In addition to being able to complete impedance testing and use Potentiostat and galvanostat testing techniques, the Solartron SI 1287 can test cyclic voltammetry. With a sleek exterior, the 1287A is 17 in x 4.25 in x 18.5 in (432 mm x 108 mm x 472 mm) and a weight of 24 lb. (11 kg). The device functions over an operating temperature range of 32 to 122°F (0 to 50°C). With a user-friendly interface, wide bandwidth, and cutting-edge technology, the 1287 Potentiostat and Galvanostat can be used with a frequency response analyzer.

Benefits of The Solartron SI 1287

ATEC offers the Solartron SI 1287A model to allow operators to measure down to 1μV for the reference electrodes and 1pA for the working electrode. This application makes the Solartron SI 1287A the ideal choice for measurements, particularly when signal levels are low. The 1287A unit also has a DC polarization voltage range of ±14.5 V and a current range of ±2 A; the AC input voltage range is ±10 V, with a gain of x1. x0.01 and an impedance of 10 kΩ.

Known for its accuracy, the Solartron SI 1287 uses floating measurements on all connections and offers complete flexibility for cell connection. The 2-terminal, 3-terminal, and 4-terminal measurement capabilities, make the Solartron SI 1287 the ideal device for a variety of testing requirements. These features allow for general materials, electrochemical, impedance testing. Specifically, corrosion and coating applications can also be utilized with 3-terminal techniques. The 4-terminal techniques allow for accurate characterization of battery and fuel cells.

Product Info

Dimensions (W x H x L)	17 in x 4.25 in x 18.5 in 432 mm x 108 mm x 472 mm
Weight	24 lb. (11 kg)
Current measurement resistor range	0.1 Ω to 1 MΩ
Cell connections	2-, 3- or 4-terminal, all floating
Maximum resolution	1 μV/ 1 pA
Operating temp. range	0 to 50ºC (32 to 122ºF)
Voltage	Range: ±14.5 V Limit of error: 0.2%±10 mV Resolution: 5 mV
Current	Ranges (full scale): 200 nA to 2 A Limit of error: 0.2%±1% of range Resolution: 1% of range
Power	14.5V/2A

2-terminal techniques for general materials/electrochemical testing
3-terminal techniques for physical electrochemistry and corrosion/coating applications
4-terminal techniques for accurate characterization of batteries/fuel cells, enabling lead resistance and impedance
Electrochemical interface
High accuracy
Wide bandwidth potentiostat/galvanostat
Full range of AC/DC test capabilities (when coupled with a frequency response analyzer)
