NDT Systems Raptor Precision Ultrasonic Flaw Detector

The NDT Systems Raptor Precision Ultrasonic Flaw Detector is a high-speed, high-resolution imaging system. Versatile and unique, B- and S-scan image generation is made simpler through key features such as a tunable wave pulser. Inspection time is also reduced by the NDT Systems Raptor due to easy result interpretation on a clear and dynamic screen. This gauge effectively analyzes metals, plastics, composites, glass, and rubber.

The NDT Systems Raptor features a sun readable full VGA display with a battery life of 8 hours. Shear mode allows for effective viewing of curved or flat surfaces. The display shows information for multiple scan types simultaneously and has direct access to submenus with the press of a key. Encased in a rugged aluminum case with rubber end caps, this compact device can be safely transported as needed.

Product Info Available Add-Ons

Dimensions	5.75 in x 9.5 in x 3.0 in (146 mm x 241 mm x 76 mm)
Weight	5.6 lbs (2.54 kg)
Power Source	Li-ion battery (autonomy of 8 hours) or AC power
Operating Temperature	32 F - 122 F (0 °C to 50 °C)
Storage Temperature	-4 F - 140 F (-20 °C to 60 °C)
Connector Type	Dual BNC
