Keysight E5080B ENA Vector Network Analyzer
- ENA vector network analyzer
- Frequency range of 9 kHz to 53 GHz
- 2 or 4 ports
Anritsu ShockLine MS46131A | 1 MHz – 43.5 GHz
- 1-port VNA with frequency options from 1 MHz to 8 GHz / 20 GHz / 43.5 GHz
- Guaranteed performance to 43.5 GHz with Extended-KTM ports
- PC control takes advantage of external computer processing power and functionality
Anritsu MS2038C VNA Master & Spectrum Analyzer | 5 kHz to 20 GHz
- 2-port, 2-path, fully-reversing VNA
- S-parameters measured with a single connection
- 350 μsec per data point
Anritsu MS46522B ShockLine 2-Port Performance VNA
- High output power allows measurement of high attenuation devices
- Advanced time domain option provides tools for signal integrity (SI) analysis
- Industry leading dynamic range enables measurement of very low reflection artifacts
Anritsu MS2034B VNA Master Vector Network Analyzer
- Frequency range of 9 kHz to 4 GHz
- Includes a powerful spectrum analyzer
- Ideal for making fast and reliable measurements in the field
Rohde & Schwarz ZNB8 Vector Network Analyzer
- Wide dynamic range of up to 140 dB
- Short sweep times of 4 ms for 401 points
- High temperature stability of typ. 0.01 dB/°C
Anritsu MS4647B VectorStar VNA | 10 MHz - 70 GHz
- 2-port vector network analyzer
- Frequency of 10 MHz to 70 GHz
- Easy-to-use applications
Anritsu MS46322B Vector Network Analyzer (VNA) | 1 MHz - 43.5 GHz
- Guaranteed performance to 43.5 GHz with Extended K™ ports
- Ideal for testing RF and microwave devices, mmWave antennas, and other passive 5G components
- Fast sweep speed and wide dynamic range minimize test times and maximize throughput
Rohde & Schwarz ZVA8 Vector Network Analyzer
- Linear and nonlinear amplifier and mixer measurements
- Noise figure measurements
- Pulse profile measurements with 12.5 ns resolution
Anritsu MS2024B VNA Master Vector Network Analyzer
- Broadband coverage of 500 kHz to 4 GHz
- 1-path, 2-port vector network analyzer
- Intuitive graphical user-interface (GUI) with convenient touchscreen
Tektronix TTR500 Series Vector Network Analyzer (VNA)
- Full 2-port 2-path S-parameter measurement (S11, S21, S12, S22) in a variety of formats.
- Complete vector network analysis capability with Tektronix VectorVu-PC™ software.
- Built-in bias tee accessible on both ports to bias active devices.
Anritsu ShockLine MS46122B | 1 MHz – 43.5 GHz
- Guaranteed performance to 43.5 GHz with Extended K™ ports
- PC control takes advantage of external computer processing power and functionality
- Compact 1U high package for efficient use of bench and rack space
Rohde & Schwarz ZVA40 Vector Network Analyzer 4 ports, 40 GHz
- Linear and nonlinear amplifier and mixer measurements
- Noise figure measurements
- Pulse profile measurements with 12.5 ns resolution
Anritsu MS2026A Vector Network Analyzer
- Frequency Range: 2 to 6000 MHz
- Frequency Accuracy: 25 ppm
- Frequency Resolution: 10 kHz
Anritsu ShockLine MS46121B | 150 kHz – 6 GHz
- 1-port VNA with frequency options from 150 kHz to 6 GHz
- External PC control enables control of multiple ShockLine MS46121B devices in parallel for excellent multisite throughput
- Very compact package allows for direct connection to the DUT
Rohde & Schwarz ZVL Vector Network Analyzers 9 kHz - 13.6 GHz
- Optional spectrum analysis and digital communications standards
- Bidirectional test set for displaying all four S-parameters
- R&S®ZVL3-75: 75 Ω vector network analyzer for TV and CATV measurements
Anritsu MS2035B VNA Master Vector Network Analyzer
- Frequency range of 9 kHz to 6 GHz
- Includes a powerful spectrum analyzer
- Ideal for making fast and reliable measurements in the field
Anritsu MS4644B 10 MHz - 40 GHz VNA
- High performance, broadband network analysis solutions
- MS4644B: (Optional 70 kHz) 10 MHz to 40 GHz
- VectorStar device
Anritsu MS46322A ShockLine Economy Vector Network Analyzer
- Ideal for testing RF and microwave devices
- Fast sweep speed and wide dynamic range minimize test times and maximize throughput
- Excellent corrected directivity allows for less measurement uncertainty
Rohde & Schwarz ZVB20 Vector Network Analyzer 4 ports, 20 GHz
- Reflectometers with separate measurement and reference channels
- Parallel measurements on multiple ports
- Data processing and transfer simultaneously with measurement
Keysight Streamline Series USB Vector Network Analyzers
- Get consistent technology, user interface, and automated code capabilities across bench, modular, and USB platforms
- Most compact VNA for easy sharing between test locations
- Wide choice of frequency ranges from 300 kHz up to 26.5 GHz
Keysight E5071C ENA Vector Network Analyzer, 9 kHz - 20 GHz
- Wide frequency coverage: 9 kHz to 20 GHz
- Low trace noise: <0.004 dB rms at 70 kHz IFBW
- Wide dynamic range: >123 dB
Keysight N5221B PNA Microwave Network Analyzer 10 MHz to 13.5 GHz
- PNA Network analyzer software tools for investigating, characterizing & troubleshooting designs
- Advanced Design System (ADS): complete, integrated set of fast and accurate circuit & system simulators
- Configurable test set
Keysight 8753E RF Network Analyzer, 30 kHz - 3/6 GHz
- 30 kHz to 3 or 6 GHz frequency range
- Integrated S-parameter test set with solid-state switching
- Up to 110 dB dynamic range
Keysight 85093C RF Electronic Calibration (ECal) Module | 3.5mm
- 300 kHz to 9 GHz frequency range
- Fast full two-port calibration with a single connection
- Simple non-insertable device calibration
