EMSCAN RFX2 Antenna Analyzer
- 300 MHz - 6 GHz
- 1,600 H-field probes max. radiator size:
- L 32 cm x W 32 cm (L 12.60” x W 12.60”) real-time scanning
AH Systems AK-18G EMC Antenna & Probe Kit | 20 Hz - 18 GHz
Electro-Metrics EM-6992 Near Field Probe Set
- Gain: 25 dB, typical
- Bandwidth (@ -3 dB): 1199.995 MHz
- Frequency Range: 5 kHz-1200 MHz
Noiseken FVC-777 EMI Noise Sensor, 30 MHz - 1 GHz
- Electric Field 100 KHz - 1000 MHz (F10006 Probe) 5.6-560mV
- Magnetic Field:100 KHz - 30 MHz (F100007 Probe) 0.01-1.0mA
- Magnetic Field: 30 MHz - 1000 MHz (F10008 Probe) 0.63-6.3mA
Y.I.C. Technologies NFPKit
- Fully integrated with Y.I.C. Technologies EMViewer Software
- Live real-time probe position tracking
- Normalization and correction when using the EMViewer Software
Y.I.C. Technologies EMScannerR | 150 kHz – 8 GHz
- Spectral scan, spatial scan, peak-hold, continuous scanning, spectral and spatial comparison, scripting, limit lines, report generation and notes
- Continuous real-time for entire scan area (1,218 probes activated) when Level 1 selected: 5 sec.
PMM SHC-1/1000 CISPR Passive Probes
- 9 kHz to 30 MHz frequency range
- CISPR 16-1-2 compliant
- Suitable for lines up to 1000 Vac - 1500 Vdc
Keysight 11941A Close Field Probe | 9 kHz - 30 MHz
- Designed to measure magnetic-field radiation from surface currents, slots, cables, and ICs for EMC diagnostic and troubleshooting measurements.
- Operates from 9 kHz to 30 MHz
- Five antenna factors for calculating absolute magnetic-field strength (dBµA/m) from dBµV reading of a spectrum analyzer.
ETS Lindgren Holaday's HI-1801 Survey Meter
EMSCAN ERX EMC Scanner
- 150 kHz - 8 GHz frequency range
- 1,218 H-field probes built in
- Customizable spatial resolution of 0.06 mm - 7.5 mm
Com-Power PS-500 Near Field Probe Set for EMI/EMC Testing
- Complete Solution - Includes E and H fi eld probes
- Contact tip probe - Make contact with the circuit
- Locate Noise Source - Down to a pin with the fi ne tip
Keysight 11940A Close Field Probe | 30 MHz - 1 GHz
- Designed to measure magnetic-field radiation from surface currents, slots, cables, and ICs for EMC diagnostic and troubleshooting measurements.
- Operates from 30 MHz to 1 GHz
- Five antenna factors for calculating absolute magnetic-field strength (dBµA/m) from dBµV reading of a spectrum analyzer.
Noiseken FVC-1000 EMI Noise Sensor, 30-1000 MHz
EMSCAN RFX Antenna Analyzer
- 300 MHz - 6 GHz frequency range
- 384 H-field probes built in
- Real time scanning with max. radiator size of L 16 cm x W 10 cm (L 6.30” x W 3.94”)
Keysight 11945A-E51 Closed Field Probe Set
- Designed to measure magnetic-field radiation from surface currents, slots, cables, and ICs for EMC diagnostic and troubleshooting measurements.
- Operates from 9 kHz to 1 GHz
- Five antenna factors with each probe for calculating absolute magnetic-field strength (dBµA/m) from dBµV reading of a spectrum analyzer.
Com-Power PS-400 Near Field Probe Set
Y.I.C. Technologies EMScanner | 150 kHz – 8 GHz
- Spectral scan, spatial scan, peak-hold, continuous scanning, spectral and spatial comparison, scripting, limit lines, and report generation.
- Continuous real-time or sub-second spatial scan time; single scan for entire scan area (dependent on spectrum analyzer performance)
- Spectral scan time of 45 seconds for a PCB with 100 MHz span and 100 kHz RBW
PMM SHC-2/1000 CISPR Passive Probes
- 9 kHz to 30 MHz frequency range
- CISPR 16-1-2 compliant
- Suitable for lines up to 1000 VAC – 1500 VDC
Keysight N9311X-100 Close Field Probe Set | 30 MHz - 3 GHz
- Frequency range: 30 MHz to 3 GHz
- Measurement tool for EMI precompliance test, troubleshooting and design verification
- Searches for sources of interference early in the design process
EMCO/ETS-Lindgren 7405 E/H Near Field Probes
- Broadband Frequency Range
- Linear Response
- Locates both E and H Field
EMSCAN ERX+ EMC Scanner
- 150 kHz - 8 GHz
- 1,218 H-field probes
- User-selected spatial resolution: 0.06 mm - 7.5 mm
