Dimensions
(L x W x H) |
11.6 in x 19.3 in x 13.7 in
29.5 cm x 49.0 cm x 34.8 cm |
Weight |
34.5 lb (15.6 kg) without batteries
38.5 lb (17.5 kg) with 4 optional batteries |
Power |
100 – 240 V
3 A
50 – 60 Hz
Optional on-board batteries and external charger |
Channel thresholds |
0.1, 0.15, 0.2, 0.25, 0.3, 0.5, 1.0, and 5.0 µm by default
All 8 channels are user-adjustable |
Counting efficiency |
50% at 0.1 µm |
Flow rate |
1 CFM (28.3 LPM)
Monitored and adjusted electronically for portable applications |
Operating temperature |
59 – 86 °F (15 – 30 °C) |
Operating humidity |
1 – 95% non-condensing |
Data storage |
10,000 data sets
Includes particle and environmental data, plus location, time, etc. |
Display |
8.4” color VGA display (640 x 480)
IR touchscreen CIP65 rated |
