Olympus DSX510 Digital Microscope

The Olympus DSX510 Digital Microscope is an all-in-one imaging system with a 69x-9014x lens, 100mm x 105 mm stage and an 11 mm working distance. Olympus DSX510 microscopes are easy-to-use, upright and ideal for industrial use. An intuitive touch-screen based user interface and up to 9,000x magnification enable users of various experience levels to obtain reliable measurement and inspection results. 3D images highlight your samples' true shape, and the Olympus DSX510 allows users to capture all-in-focus images, even for samples with projections. Measurement accuracy is guaranteed and an array of measurement and analysis tools are offered, including surface roughness measurement.

Product Info Related Products

Model	DSX510
Zoom ratio	13.5X optical zoom (0.26X to 3.5X), 30X with digital zoom
Motorized stage stroke	100 x 100 mm
Manual stage stroke	100 x 105 mm
Number of attaching objective lenses	up to 2 pieces
Mountable DSX dedicated objective lens	XLMPLFLN10X, XLMPLFLN40X
Mountable UIS2 objective lens	MPLFLN1.25X, MPLFLN2.5X, MPLFLN5XBDP, MPLFLN10XBDP, MPLFLN20XBDP, MPLFLN50XBDP, LMPLFLN10XBD, LMPLFLN20X, LMPLFLN50X, MPLAPON50X
Accuracy of magnification (X-Y plane)	±3%
Repeatability of magnification	3 O_n-1= ±2%
Repeatability (Z axis) height	O_n-1≤1μm
Embedded standard illumination	Bright field: LED, Dark field: LED
Optional illumination	High intensity LED/Transmitted LED
Image sensor	1/1.8 inch, 2.01 megapixels, color CCD (total pixels: 2.10 megapixels) Total pixels : 1688 (H) x 1248 (V) Available pixels : 1628 (H) x 1236 (V) Effective pixels : 1600 (H) x 1200 (V)
Cooling method	Peltier cooling
Scan mode	Progressive scan
Frame rate	15 fps/27 fps with binning mode
Image size	Normal : 1194 x 1194 (1:1)/1592 x 1194 (4:3) Fine : 1194 x 1194 (1:1)/1592 x 1194 (4:3) Super fine : 3594 x 3594 (1:1)/4792 x 3594 (4:3)
Sensitivity	ISO 100/200/400/800/1600 equivalent
Stroke	95 mm
Resolution	0.01 μm
DSX dedicated objective lens max. sample height	65 mm
UIS2 objective lens max. sample height	95 mm
Motorized stage model	DSX-UFSSU
Motorized stage load capacity	3 kg
Manual stage model	U-SIC4R2
Manual stage load capacity	1 kg
LCD monitor size	23” with touch panel and Full HD color LCD monitor
LCD monitor resolution	1920 (H) x 1080 (V)
Weight (Main frame, Motorized stage, LCD monitor, Control box, Controller)	Approx. 38.6 kg
Input rating	100-120 V/220-240 V, 300 V A, 50/60 Hz

Digital microscope that performs 3D & surface roughness measurements
High NA — low-aberration field lenses
High-resolution 18MP images reproduced with high-performance CCD
Optical zoom of up to 13X and digital zoom of up to 30X
Brightfield, darkfield, BF + DF, differential interference contrast and polarized light observation methods available
HDR visuals processed by WiDER high-contrast solution
Low center of gravity, sturdy frame
Automatically generates custom reports with customizable templates
