Keysight InfiniiVision DSO7104B Oscilloscope 1 GHz
- 100 MHz, 350 MHz, 500 MHz and 1 GHz models
- Up to 4 GSa/s sample rate
- 2+16 & 4+16 Channel mixed signal (MSO) models
Yokogawa DL750 ScopeCorder 10 MS/s, 16 Channel, 8 Slots
- Integration of a High-Speed sampler (Oscilloscope) and Low-Speed sampler (Recorder) in a Single Unit
- Separate Memory Management for Each sampler
- High-Speed Sampling Triggered Only by Abnormal Events Occurring during Long-Term Observation (Low-Speed Sampling)
Tektronix 5 Series MSO Mixed Signal Oscilloscopes
Yokogawa DLM4000 MSO Series
- Max. nondestructive input voltage ±40 V
- Analog Input 1 MΩ ±1.0%
- Maximum sampling rate 1.25 GS/s
Tektronix DPO3054 Digital Oscilloscope 500 MHz, 2.5 GS/s
- Bandwidth: 500MHz
- Channels: 4
- Sample Rate: 2.5 GS/s
Tektronix MSO46 Mixed Signal Oscilloscope
- 13.3-inch HD display
- 6.1-inch (15.5 cm) deep bench-friendly footprint
- Any channel can show a waveform, spectrum, or both
Tektronix DPO7254 Digital Oscilloscope 2.5 GHz, 4 CH
- Up to 40 GS/s Real-time Sample Rate on One Channel and up to 10 GS/s on All Four Channels
- Up to 500 Megasamples Record Length with MultiView Zoom™ Feature for Quick Navigation
- >250,000 wfms/s Maximum Waveform Capture Rate Up to 310,000 Waveforms per Second with FastFrame™ Segmented Memory Acquisition Mode
Tektronix MSO72304DX Mixed Signal Oscilloscope
- High-speed serial industry standards compliance
- MultiView Zoom
- Low jitter noise floor and high vertical accuracy
Fluke 190 Series II ScopeMeter Test Tools
- Four electrically isolated inputs
- CAT III 1000 V / CAT IV 600 V safety rated
- Choose from 60 MHz, 100MHz, 200MHz or 500MHz bandwidth models
Tektronix MDO4014-3 Mixed Domain Oscilloscope
- Mixed-domain analysis Time-correlated analog, digital, and RF signal acquisitions in a single instrument Wave Inspector controls provide easy navigation of time-correlated data from both the
- Time-correlated analog, digital, and RF signal acquisitions in a single instrument
- Wave Inspector controls provide easy navigation of time-correlated data from both the time and frequency domains
Keysight DSAX92004A Infiniium High-Performance Oscilloscope 20 GHz
- 20 GHz true analog bandwidth, upgradable to 33 GHz
- 80 GSa/s sample rate 2 channels / 40 GSa/s sample rate 4 channels
- Industry deepest memory with up to 2 Gpts memory (50 Mpts per channel standard)
Teledyne LeCroy HDO4034 High Definition Oscilloscope 350 MHz, 2.5 GS/s
- 12-bit ADC resolution, up to 15 bit with enhanced resolution
- 350 MHz bandwidth
- Long Memory – up to 25 Mpts/Ch (50 Mpts interleaved)
Tektronix TDS5054B 4 Channel 500 MHz 5 GS/s Digital Oscilloscope
- 500 MHz Bandwidth Model
- 4 Channel Models
- 5 GS/s Sample Rate
Tektronix MSO22 Mixed Signal Oscilloscope
- Compact, versatile oscilloscope for daily debug
- Intuitive touchscreen with simplified front panel
- Easy-to-use interface with comprehensive analysis for fast insight
LeCroy WavePro 960 Digital Oscilloscope 2 GHz
- Bandwidth: 2 GHz
- Max Sample Rate: 16 GS/s
- Acquisition Memory: Standard 1 Mpts-Optional 4-64 Mpts (1 Ch)
LeCroy WaveRunner 64 Xi Oscilloscope 600 MHz, 4 Ch
- Sequence Acquisition Mode to optimize capture, viewing, and understanding of events that are spaced far apart in time.
- Extensive pass/fail capability with multiple conditions and limits, and flexibility to choose the action that is enabled when the conditions are satisfied.
- Creation of user-customized measurement parameters or math functions using Excel, MATLAB, Mathcad or VBScripts.
Agilent 1134A InfiniiMax 7 GHz Active Probe
- Supports differential and single-ended measurements
- Common mode rejection of the differential probe reduces the noise floor
- Flat frequency response to eliminate distortion
LeCroy WM8300A Digital Oscilloscope 3 GHz, 20 GS/s
- High bandwidth from 3 GHz to 6 GHz
- Fast sampling speeds-to 20 GS/s on 4 channels
- Full sampling speed maintained over entire memory length
Tektronix TDP1000 High Voltage Differential Probe | 1 GHz
- 1 GHz probe bandwidth
- Selectable bandwidth-limiting filters
- Versatile DUT connectivity
Tektronix MSO4104 Mixed Signal Oscilloscope | 1 GHz, 4 CH
Tektronix DPO71604B Digital Phosphor Oscilloscope, 16 GHz, 4 Ch, 50 GS/s
- Pinpoint Triggering – Minimize time spent trying to acquire problem signals for efficient troubleshooting and shortened debug time
- Signal Integrity, Jitter, and Timing Analysis
- Memory Bus Analysis and Debug
Fluke 190-502 | 500 MHz 5 GS/s 2 channel
- Up to four independent floating isolated inputs, up to 1000 V Up to 5 GS/s real time sampling (Depending on model and channels used)
- Deep memory: 10,000 points per trace waveform capture (scope mode)
- CAT III 1000 V/CAT IV 600 V safety rated instrument for industrial environments
LeCroy WaveSurfer 104MXS-B Digital Oscilloscope 1 GHz
Tektronix MDO4054B-6 Mixed Domain Oscilloscope
- Mixed-domain analysis Time-correlated analog, digital, and RF signal acquisitions in a single instrument Wave Inspector controls provide easy navigation of time-correlated data from both the
- Time-correlated analog, digital, and RF signal acquisitions in a single instrument
- Wave Inspector controls provide easy navigation of time-correlated data from both the time and frequency domains
Rohde & Schwarz RTO2000 Oscilloscopes
- Bandwidth frequency range of 600 MHz to 4 GHz and expandable up to 6 GHz
- Vertical resolution: up to 16-bit with HD mode option
- MSO: 16 digital channels
