Keysight PA2203A IntegraVision Power Analyzer | 4 Channels, 3-Phase AC
The Keysight PA2203A IntegraVision power analyzer is a 4-channel, 3-phase AC precision power analysis system that synthesizes the high accuracy of a power analyzer and the enhanced customer experience of an oscilloscope. Keysight PA2203A IntegraVision power analyzers are designed to reduce setup time and streamline testing, allowing users to quickly perform a variety of test scenarios with broad, isolated inputs. The PA2203A creates visualizations of transients, in-rush currents, and other state changes, its high-speed digitizer capturing real-time power, current, and voltage data. All of this is performed on a 12.1” / 310 mm touchscreen display. R&D engineers choose the IntegraVision PA2203A because of it provides highly accurate dynamic measurements and power measurements that vary vs. time; these qualities make it a vital tool in reducing energy consumption, increasing efficiency in power conversions, and developing devices that take power from AC lines.
| Basic Accuracy (50/60 Hz) | 0.05% |
| Best Power Accuracy | 0.1% |
| Maximum rms Voltage | 1000 V/2000 V Peak |
| Channels | 4 |
| Sampling Rate | 5 M Sa/s |
| 3-Phase Analysis | Yes |
| Phase AC | 3 |
| Maximum Current Direct Input | 2 A / 6 A Peak |
| Bandwidth | 2.5 MHz |
- Operates like an oscilloscope, but makes measurements like a power analyzer
- Achieve 0.05% basic accuracy for superior measurement integrity
- The PA2201A comes with 2 power channels for single phase measurements and analysis; the PA2203 has 4 power channels for 3-phase measurement and analysis
- Provides isolated inputs for easy and safe connections
- Capture waveforms with 5 M sample/second digitizer
- Visualize voltage, current and power waveforms in real-time to gain insight into your device
- Save space with a small footprint
- Clearly see waveform details on a large gesture-enabled touchscreen
- AC/DC power supplies
- DC/AC inverters
- DC/DC converters
- Solar inverters
- Hybrid Electric Vehicles (HEV), Electric Vehicles (EV), and Plug-in Hybrid Electric Vehicles (PHEV) inverters
- UPS
- Battery powered backup and standby systems
- Battery chargers
- Charging stations
- Battery management systems
- Energy storage systems
- Lighting
- Appliances
- Industrial machines
- Robotics
