Thermo Keytek Series 2000 Electrostatic Discharge Test System
- 0 to 25 kV bipolar
- Plug-in, interchangeable discharge networks for different human body models
- Separate simulations for all six key simulation modes at discharge and its five components
Static Control Solutions (SCS) 770045 EOS/ESD Assessment Kit
- EOS/ESD assessment kit
- Offers an effective way to detect ESD events and troubleshoot
- Verify that the ESD control processes are working properly
Electro-Tech 949-2 IEC 61000-4-2 Verification Kit
- 2.5GHz frequency response
- 1A/V to 50Ohm load transconductance
- IEC61000-4-2 compliant
EM Test Dito 16.5 kV ESD Simulator for IEC 61000-4-2
- Most ergonomic design
- Light weight (940g)
- Interchangeable discharge tips
EMC Partner DM1 Electrostatic Discharge Module for IEC 61000-4-2, ITU-T K20 (ESD3000DM1)
3ctest EDS 20H Handheld Electrostatic Discharge Simulator, 20kV
- Ergonomic design
- LCD touch screen
- All-in-one design (no base unit)
Electro-Metrics EDS-250/300 Electrostatic Discharge Simulators
- Electro-Metrics® Electrostatic Discharge Simulators are designed to meet existing and proposed standards
- Common control unit (250/300)
- Generates repeatable, fast risetime, high voltage waveforms
3ctest EDS 30T Electrostatic Discharge Simulator, 30kV
- Ergonomic design
- LCD touch screen
- All-in-one design (no base unit)
ESDEMC ES613 | 30 kV
- The most ergonomically designed ESD Gun
- Ultra Light Weight ESD Gun (< 700 g, the lightest one in the market)
- Integrated automatic charge removal circuit
EMC Partner ESD3000 ESD Gun | 16 kv, 30 kV
- 30 kV contact discharge level
- Single impulse mode
- Simple operation
EM Test ESD 30N Electrostatic Discharge Simulator
- Test voltage up to 30kV for air and contact discharge
- Discharges up to 20Hz
- Easy-to-change R/C-networks and tips
Noiseken ESS-2000AX | 30 kV
- Fully programmable menu-driven simulator providing three operation modes: IEC standard, Manual and Sequence
- A 5.7-inch color LCD for easy setting and good visibility
- Unique shape for the operator's easy access to the controls and displays even when the unit is put on the floor level (ground plane)
Noiseken ESS-6002 Component Level Electrostatic Discharge Simulator
- 8kV maximum output (ESS-6008)
- 10V minimum output (1V step) (ESS-6002)
- A simple probe stand and test fixture plus a pair of miniature test leads meeting many different kinds of device packages (Free Board Type)
Noiseken ESS-6008 Component Level Electrostatic Discharge Simulator
- 8kV maximum output (ESS-6008)
- 10V minimum output (1V step) (ESS-6002)
- A simple probe stand and test fixture plus a pair of miniature test leads meeting many different kinds of device packages (Free Board Type)
Noiseken ESS-S3011/GT-30R ESD Gun | 30 kV
- Infrared remote control
- 3 pre-checking function to ensure testing efficacy is confirmable
- One touch exchanges gun head and CR unit
Noiseken ESS-S3011A/GT-30RA | 30 kV
- Pre-test: "3 pre-checking functions” taking the confirmable test into the account. "CR constant indicator” to ensure correct attachment is in place.
- During test: “Ten-key & Rotary knob” to ease the setting. “Infra-red Remote Controller” to allow remote Generator setting. “Discharge Detecting Function” to
- After test: “Control Software” for Test Result Reporting and PC Control. Free-downloadable from NoiseKen web-site.
Haefely RC Module Discharge Networks
Teseq INA Custom Discharge Networks
- Custom discharge network
- Used with the Teseq NSG 438 and EM Test NX30
- Available with multiple configurations
Teseq MD103 ESD Pulse Calibration Set
- Target for precise ESD pulse measurements
- Very small insertion loss variation
- Precise gold plated construction
M Precision Laboratories MZ-15/EC MiniZap | 15 kV
- Intuitive operation.
- Portable & self-contained.
- Meets exact requirements of IEC 61000-4-2.
Teseq (Schaffner) NSG430 Electrostatic Discharge Simulator
- Rise Time: 5ns ±30% at 2kV
- Discharge voltage: 2 - 16.5kV
- Polarity: positive / negative - non switchable
Teseq (Schaffner) NSG 431 Electrostatic Discharge Simulator
- Fulfills standards such as IEC, ANSI-IEEE, VDE, NAMAR, MIL, SAE
- H and E field adapters
- Relay unit (contact discharge adapter)
Teseq (Schaffner) NSG432 Static Discharge Simulator
Teseq NSG 435 | 16.5 kV
- Use- programmable discharge voltage - 200V to 16.5 kV
- Polarity - manual setting to +ve or -ve, and automatic switching between the two.
- Battery powered
Teseq NSG 437 | 30 kV
- Possesses both air and contact discharge up to 30 kV
- LCD touchscreen front panel controls
- Features advanced voltage-hold capabilities
Teseq NSG 438 ESD Gun | 30 kV
- Air and contact discharge 0.2kV to 30 kV
- Touch panel display controlled
- Battery powered
Teseq NSG 438A | 30 kV
- Integrated discharge relay (Bleed-Off resistor)
- Suitable for conventional ESD testing as well as for ungrounded EUT’s
- Controlled and reproducible discharge and observation time periods
EM Test ESD NX30 | 30 kV
- Test voltage up to 30 kV for air and contact discharge
- Color touch display
- Discharges up to 25 Hz
Haefely ONYX 16 | 16 kV
- User defined 'smart key' function
- Touch screen interface
- Ergonomic design
Haefely ONYX 30 | 30 kV
- User defined 'smart key' function
- Touch screen interface
- Ergonomic design
EM Test P18 Electrostatic Discharge Simulator
- Switchable bleedoff/charge remover
- 150 pF / 330 ohm
- Positive and negative probe
Haefely PESD 3010 Electrostatic Discharge Generator
Haefely PESD1600 ESD Simulator Gun
- Voltage: 1 - 30 kV
- Pulse networks: 150 pF / 330 ohm
- Air discharge tip
Schloder SESD 216 ESD Gun | 16.5 kV
- IEC 61000-4-2 (150 pF / 330 Ohm)
- 16.5 kV Air / 10 kV Contact discharge
- Predefined tests – Standard and others
Schloder SESD 230 ESD Simulator, 30 kV
- IEC 61000-4-2 (150 pF / 330 Ohm)
- 30 kV AIR and CON discharge
- Battery or mains operation
Schloder SESD 3000 ESD Simulator, 30 kV
- Capacity modules available up to 1000 pF
- Resistor modules available from 50 Ohm up to > 5 kohm; Special module 0 Ohm (only for air discharge)
- Automatic polarity switching module (optional)
