AE Techron 3110 Standards Waveform Generator
- Includes a large library of Automotive and Aviation Standards’ test routines--complete list available as Supplemental Document under Datasheet on left
- Drag and drop interface makes it easy to modify existing tests or build new waveform sequences
- Loop entire tests or test sections; repeat loops with increments of up to four variables
AE Techron 3110A Standards Waveform Generator
- Easiest-to-use LF wave sequence generator
- 1550+ automotive and aviation standards' tests included
- Dramatically reduces test time for repetitive test sequences
AE Techron 7224 Power Amplifier | DC - 300kHz, 900VA
- Frequency bandwidth of DC to 300 kHz at rated power.
- Continuous output of over 1,100 watts RMS at 4 ohms.
- 40 mSec pulses of up to 52 amperes peak into a 0.5 ohm load.
AE Techron 7228 Linear Power Amplifier | 1000 W, 100kHz - 1MHz
- Up to 4X the long-term power of the 7224 at frequencies above 100 kHz
- Changes to protection, connection type and modes of operation are accomplished quickly by changing back-panel DIP switches or via remote contact closure
- Provides user-selectable current limit, DC Blocking and DC Servo for transformer-based loads
AE Techron 7234 Audio Power Amplifier
- Bench-sized
- Single-phase
- Drop outs and surges as fast as 1.2µs
AE Techron 8302 RF Amplifier
- Part of the 8300 Series
- Revolutionary switch-mode design
- Wide bandwidth and flexible
Amplifier Research CI00250A RF Conducted Immunity System
Amplifier Research CI00400A RF Conducted Immunity System
Amplifier Research CI00402 RF Conducted Immunity System
- Fully self-contained state of the art system designed to test RF conducted immunity
- The system contains a signal generator a spectrum analyzer a 100W nominal AR amplifier a 10 kHz to 400 MHz directional coupler emcware® control software
- a signal generator
AE Techron CIS-25 EMC Testing Kit
- Combines into a single, complete package the items needed to accurately test to important Aviation standards like DO-160 sections 18 and 19
- Included with the kit are three coupling transformers (T1000, T2000, and T3700)
- Includes the DSR 100-25 test system and the CR 600 Chattering Relay accessory
AE Techron DSR 100-200 | Pulse 2B and 4
- 4-Quadrant – Can source and sink current.
- ±80V – DC supply for 12V to 48V systems; meets 80V surge requirements.
- 300 kHz Sine – DC ripple tests for all major standards.
Amplifier Research MT06000 Multistar Multi-tone RF Radiated Immunity System 80 MHz - 6 GHz
AE Techron T1000 Magnetic-Field Susceptibility Transformer
- Up to 100ARMS secondary current.
- Exceeds AF Magnetic Field test requirements of DO 160 Section 19 and Boeing D6-16050-5 Section 7.2.2.
- Circuit breaker protected from over-current.
AE Techron T2000 Low-Frequency Conducted Susceptibility Transformer
- Frequency response: 10 Hz to 250 kHz.
- Turns ratio: 2:1 step down
- Audio power: 200W
AE Techron T3700 Electric-Field Susceptibility Transformer
- Up to 3,700 volts, 11,000 V/m.
- Meets or exceeds voltage requirements of DO 160 Section 19 and Boeing D6-16050-5 Section 7.2.
- Robust design; withstand tested to 5,000VRMS.
BOLAB 100-TS Series | DC – 200 kHz, 400 W – 18000 W
- DC to 200 kHz full range bandwidth
- Rise time / fall time up to 100 V/µs
- Arbitrary function with 1 Million memory data points
Pearson Electronics 101 Current Monitor Probe | 0.25Hz - 4MHz
Pearson Electronics 110 Current Monitor Probe | 1Hz – 20MHz
- Current monitor probe
- Robust peak current capacity of 5 kA
- Frequency response reaching up to 20 MHz
PMM 150-50-BCL Ohm Adapter
- 3 watts power rating
- Conducted immunity system testing
- Frequency range of 10 kHz to 230 MHz
California Instruments 15003iX Programmable 15 kVA Power Supply
- Combination AC and DC Power Source and Power Analyzer (Replaces several instruments with a single multifunction unit)
- 3000 VA to 30000 VA of Output Power (Capable of handling a wide range of loads with 0 to 1 power factor)
- Arbitrary Waveform Generation (Test products for harmonics immunity)
Solar 2352-1 Audio Power Amplifier, 15 Hz - 150 KHz
Solar 2654-2 Lightning Transient Generator System for DO-160
- The controller and power supply module
- Waveform timing
- The high voltage power supply
Solar 2854-1 Transient Generator
- For MIL-STD-461F CS106 conducted transient susceptibility test
- Adjustable pulse position on AC lines relates the transient susceptibility to real time aspects of digital systems
- Single-pulse feature for controlled isolation of transient effects
Solar 2854-2 Spike Generator
- Provides output levels from 10 V to more than 400 V into 5 Ω
- Adjustable pulse position on AC lines relates the transient susceptibility to real time aspects of digital systems
- Single pulse feature for controlled isolation of transient eects
Pacific Power 3150AFX AC & DC Programmable Power Source
- AC output, DC output, AC+DC output
- DC, 15 to 1,200 Hz frequency range
- Single, constant power mode 300V L-N/520V L-L/425Vdc voltage range offers wider operating range
Pearson Electronics 3525 Current Monitor | 5 Hz – 15 MHz
- 0.1 V/A +1/-0% sensitivity
- 50 Ω output resistance
- Maximum peak current of 5000 A
Teseq NSG 4070B
- Integrated signal generator 9 kHz – 1 GHz
- 3 power meter inputs 9 kHz – 1 GHz
- Integrated class A power amplifier module for different applications: 35 W, 150 kHz – 230 MHz; 40 W, 10 kHz – 400 MHz 45 W, 9 kHz – 1 GHz; 80 W, 150 kHz
California Instruments 5001iX AC Power Source
- Combination AC and DC Power Source and Power Analyzer
- 3000 VA - 15000 VA of Output Power
- Arbitrary Waveform Generation
Solar 6254-5S RFI Transient Generator
- Spike Amplitude: Continuously adjustable from less than 10 volts to more than 250 volts peak.
- Repetition Rate: Continuously adjustable from 0.5 to 500 p.p.s.
- Rise Time: Less than 1.0 microsecond.
Solar 6552-1A 10 Hz - 100 kHz, 100 Watt Audio Amplifier
- Input Voltage: 0.6 volt for maximum power output at 1000 Hz.
- Input Impedance: 500-600 ohms.
- Output Power: 100 watts at 1 KHz into 2.4 ohms.
Solar 7054-1 Spike Generator for MIL-STD-461 CS106
- Provides output levels from 10 volts to more than 600 volts into 5 ohms or less. Delivers more than 300 kw peak into 0.5 ohms load.
- Adjustable pulse position on a.c. lines relates the transient susceptibility to real time aspects of digital systems.
- Single pulse feature for controlled isolation of transient effects.
Solar 7054-2 Spike Generator 600 V
- 10 V to 600 V Output
- Delivers < 300 kW Peak to a .5 Ω Load
- Pulse Position on AC Lines Adjustable - Relates Transient Immunity to Real Time Aspects
Solar 7054-2B Spike Generator
- 0° to 360°
- Periodically 50, 60 or 400 Hz Sine Wave
- Provides output levels from 10 V to 400 V into 5 Ω. Delivers more than 300 kW peak into 0.5 Ω load
Solar 7399-2 2,500 Volt Spike Generator for MIL-STD-1399
- Repetitive spikes up to 2500 volts peak at two pulses per minute.
- Single non-synchronous spike actuated by a push button on the panel.
- Sync functions provide for placing the spike on the power frequency waveform of 50, 60 or 400 Hz power lines. The spike can be moved to any point of the sine wave from 0 to 360°
Solar 7541-1 Spike Receptor Probe
- Spike receptor probe (calibrated for use with oscilloscope)
- The receptor probe is assembled with a hinged construction
- Includes a calibrating resistor mounted in the housing
Solar 8282-1 Transient Pulse Generator
- Provides outputs up to 600 volts peak amplitude for the 0.15, 5.0 and 10.0 S spikes into a five ohm resistive load (low source impedance).
- A wide range of repetition rates allows spike injection in terms of the pulse rates of items being tested.
- The single pulse feature enables controlled isolation of transient effects.
Solar 8850-1 Sweep Generator for MIL-STD-461 CS01/CS101
- Manual or automatic frequency sweep from 30 Hz to 100KHz
- Digital display of frequency and output voltage level or injection voltage level
- Remote sensing of voltage being injected into the Equipment Under Test
Solar 8850-2 High Power Sweep Generator
- Manual or automatic frequency sweep from 30 Hz to 150 KHz
- Digital display of frequency and output voltage level or injected voltage level
- Remote sensing of voltage being injected into the Equipment Under Test
Solar 9108-1N Clamp-On Injection Probe | 10 KHz – 200 MHz
- Bulk current injection probe
- Frequency range of 10 kHz and 200 MHz
- 1.25-inch diameter window
Solar 9120-1N Injection Probe
- Injection probe
- Split toroidal design for easy clamping onto test wires
- Calibrated for insertion loss and transfer impedance
Solar 9123-1 Current Monitor Probe | 10 kHz – 500 MHz
- Bulk current injection probe for EMI testing
- Clamp-on design
- Frequency range of 10 kHz to 500 MHz
Solar 9142-1N Bulk Current Injection Probe | 2 MHz – 450 MHz
- Bulk current injection probe
- Frequency range of 2 MHz to 450 MHz
- Maximum input power of 200 W
Solar 9144-1N Injection Probe
- Injection probe
- Unique split toroidal structure
- Designed to maintain a low voltage standing wave ratio
Solar 9335-2 Multiple Impedance Coupling Device
Solar 9354-1
- Panel mounted digital Voltmeter displays the open circuit discharge voltage
- Automatic or manual trigger for damped sinewave. Manual only for double exponential pulses
- Variable peak output voltage (adjustable from 0.1 to 100% of selected circuit discharge voltage
Solar 9354-2 Transient Generator for MIL-STD-461 and DO-160
- Panel-mounted digital voltmeter. Monitors the adjusted open circuit discharge voltage
- Pulse rates up to one pulse per second maximum (factory adjusted)
- Single pulse feature enables controlled isolation of transient effects
Solar 9355-1 for MIL-STD-461D/E CS115
- Panel-mounted digital meters monitor the adjustable charged line voltage and pulse repetition rate.
- Adjustable pulse rate from 0.6 p.p.s. to 150 p.p.s., and manual triggering via front panel push button.
- Charged line output voltage adjustable from 1.0 V to >2000 V
ETS-Lindgren 95236-1 Bulk Current Injection Probe
Solar Electronics 9554 Variable Frequency Modules
- Variable frequency modules
- Comes in several configurations
- Specialized module for military and aerospace applications
Solar 9719-1N Injection Probe
- Bulk current injection probe
- Has a frequency range of 10 kHz to 350 MHz
- Designed for continuous 30-minute use at full power
BOLAB AN-ABCD-300-C10 Artificial Network System | 1000 V, 300 A
- In accordance with LV123, ISO 21498, MBN 11123, VW 80300, and IEC 61851-23
- Liquid cooled for stabile resistance temperature and constant ohmic value
- True continues current loading without derating, ideal for in-the-loop testing during the development stage of HV components
Bolab AN-ABCD-60 Artificial Network System | 1000 V, 60 A
- In accordance with LV123, ISO 21498, MBN 11123, VW 80300, and IEC 61851-23
- Liquid cooled for stable resistance temperature and constant ohmic value
- True continues current loading without derating, ideal for in-the-loop testing during the development stage of HV components
Fischer Custom Communications BCICF-1 Calibration Fixture
- Excellent VSWR over a broad bandwidth: <2:1 over the frequency range of 10kHz – 400 MHz when the probe is in fixture
- Accommodates a wide variety of Bulk Current Injection Probes that operate between 10 kHz – 400 MHz
Fischer Custom Communications FCC-BCICF-2
- Bulk current injection probe fixture
- Matched with the F-140 bulk current injection probe
- Easy-to-use design
AH Systems BCP-510 Broadband Current Probe | 20Hz - 1MHz
- Measures currents on 50 Hz, 60 Hz and 400 Hz powerlines
- Individually Calibrated (Transfer Impedance calibration included)
- Split Type Clamp-on Design
AH Systems BCP-511 Broadband Current Probe | 20 kHz – 100 MHz
- Measure conducted emissions from 20 kHz to 100 MHz
- Capable of measuring pulse currents up to 100 amperes with a duty cycle of 0.001
- Individually calibrated (transfer impedance calibration included)
AH Systems BCP-512 Broadband Current Probe | 1MHz - 1000MHz
- Individually Calibrated (Transfer Impedance calibration included)
- High Current Capability
- Split Type Clamp-on Design
AH Systems BCP-520 Broadband Current | 10kHz - 500MHz
- Individually Calibrated (Transfer Impedance calibration included)
- High current conducted emissions measurements without saturation
- High Current Capability
AH Systems BCP-526 Broadband Current Probe | 100kHz - 1GHz
- High current conducted emissions measurements without saturation.
- Individually Calibrated (Transfer Impedance calibration included)
- High Current Capability
AH Systems BCP 600 Series | 20 Hz – 500 MHz
- A variety of current probe configurations
- Frequencies ranging from 20 Hz to 500 MHz
- Lightweight designs
BOLAB Systems BLS-130-70N-TS 4-Quadrant Voltage Amplifier
- DC to 200 kHz full range bandwidth
- DC up to 1 MHz (small signal -3 dB)
- Option for running as a current amplifier
Schloder CDG7000 Conducted Disturbances Test System
- Compact device
- Consists of an RF signal generator, an RF-power amplifier, a 3-channel RF voltmeter, and a directional coupler
- RF power amplifier is available in three different models
Com-Power CDN-AF2 Coupling/Decoupling Network (CDN)
PMM CDN-AF2 Coupling Decoupling Network
- 150 kHz - 230 MHz
- 4 mm Safety Lab Connectors
- 250 V AC / 250 V DC
Schwarzbeck CDN-AF2
- Part of the coupling decoupling network series
- For conducted common mode immunity testing according to IEC 61000-4-6
- Frequency range of 0.15 - 230 MHz
Com-Power CDN-AF4 Coupling/Decoupling Network (CDN)
Schwarzbeck CDN-AF4
- Part of the coupling decoupling network series
- For conducted common mode immunity testing
- Intended to inject common mode disturbance signals to control lines
Com-Power CDN-AF8 Coupling/Decoupling Network (CDN)
Com-Power CDN-C75 Coupling/Decoupling Network (CDN)
Com-Power CDN-M125E Couplers Coaxial
- Frequency Range - 150 kHz -230 MHz
- Meets EN 61000-4-6 requirements
- Current Rating: up to 25 Amps
EM Test CDN-M2/M3N for Supply Lines
- For 2 or 3 AC/DC supply lines (switchable)
- AE: IEC 320 connector
- EUT: 4mm safety lab connectors
Schwarzbeck CDN M2/M3PE-16A
- Part of Schwarzbeck's coupling decoupling network series
- For conducted common mode immunity testing according to IEC 61000-4-6
- Immunity testing on unscreened AC and DC power supply lines (mains lines)
Com-Power CDN-M225E Coupling/Decoupling Network (CDN)
- Frequency Range - 150 kHz - 230 MHz
- Meets EN 61000-4-6 requirements
- Current Rating: 25 Amps
Com-Power CDN-M325 Coupling/Decoupling Network (CDN)
Schwarzbeck CDN-M4-63A-1000V
- Part of the coupling decoupling network series
- For conducted common mode immunity testing
- Suitable for immunity testing on unscreened AC and DC power supply lines
Com-Power CDN-M425 Coupling/Decoupling Network (CDN)
- Frequency Range - 150 kHz - 80 MHz
- Meets EN 61000-4-6 requirements
- Current Rating: up to 25 Amps
Schwarzbeck CDN M4PE-32A-1000V
- Intended to inject common mode disturbance signals to power supply or mains lines
- Frequency range of 150 kHz to 230 MHz
- Complies with the requirements of IEC 61000-4-6
Com-Power CDN-M525 Coupling/Decoupling Network (CDN)
Com-Power CDN-M525E Five Conductor Power Line 25 Amp CDN
- Product Name: Coupling Decoupling Network (CDN)
- Compliant Test Standards: IEC / EN 61000-4-6
- Application: Five conductor power cable
Schwarzbeck CDN-M5PE 125A 1000V
- Sufficient decoupling between Auxiliary Equipment (AE) and disturbance signal
- Available for a multitude of cable types and connectors
- In compliance to IEC 61000-4-6
_24.jpg)
Schwarzbeck CDN-M5PE-32A-1000V
- Part of the coupling decoupling network series
- For conducted common mode immunity testing according to IEC 61000-4-6
- Frequency range of 150 kHz to 230 MHz
_24.jpg)
Schwarzbeck CDN M5PE 63A 1000V
- Part of the coupling decoupling network series
- For conducted common mode immunity testing, according to IEC 61000-4-6
- Frequency range of 150 kHz - 230 MHz
Com-Power CDN-S1 Coupling/Decoupling Network (CDN)
- For Signal Lines
- Frequency Range - 150 kHz - 80 MHz
- Meets EN 61000-4-6 Requirements
Com-Power CDN-S2 2 Wire Coupling/Decoupling Network (CDN)
- For Signal Lines
- Frequency Range - 150 kHz - 80 MHz
- Meets EN 61000-4-6 Requirements
Schwarzbeck CDN-S25-SUBD
- Part of the coupling decoupling network series
- For conducted common mode immunity testing according to IEC 61000-4-6
- Frequency range of 10 kHz to 230 MHz
Com-Power CDN-S4 4 Wire Coupling/Decoupling Networks (CDN)
Com-Power CDN-T2 Coupling/Decoupling Network (CDN)
- For Signal Lines
- Frequency Range - 150 kHz - 80 MHz
- Meets EN 61000-4-6 Requirements
Com-Power CDN-T4 Coupling/Decoupling Network (CDN)
Schwarzbeck CDN-T4-RJ45
- Part of the coupling decoupling network series
- Frequency range of 10 kHz to 230 MHz
- For conducted common mode immunity testing
Schwarzbeck CDN-T8-RJ45
- Part of the coupling decoupling network series
- For conducted common mode immunity testing according to IEC 61000-4-6
- Frequency range of 10 kHz to 230 MHz
Com-Power CDN-T8E CDN for 8 Line (4 Balanced Pairs)
- Frequency range of 150 kHz to 230 MHz
- Designed for IEC / EN 61000-4-6
- Four unscreened, balanced pairs
Com-Power CDN-USB-AE Coupling Decoupling Network
- Frequency range 150 MHz-230 MHz
- Meets CISPR 16-1-2 requirements
- USB cables with type A connector
Teseq CDN USB/P Coupling/Decoupling Network
- Designed for IEC/EN 61000-4-6
- USB/p for test peripheral devices
Frankonia CIT-10 Compact Immunity Test System, 10 kHz - 400 MHz
- Conducted RF immunity tests acc. to IEC/EN 61000-4-6 and BCI tests acc. to ISO 11452-4 and MIL–STD 461E
- Signal generator, RF-power amplifier, RF-power meter and directional coupler (optional) in one 19”-case
- Stand-alone operation possible with optional available netbook
Frankonia CIT-1000 Conducted Immunity Test System
- Conducted RF immunity tests acc. to IEC/EN 61000-4-6, BCI-tests acc. to ISO 11452-4 and MIL-STD 46
- Signal generator, RF-Power-Amplifier, 3-channel power-meter and directional coupler combined in one 19“ case.
- Stand-alone operation via integrated touchscreen PC
PMM CLA-050 Absorbing Clamp 30 MHz - 1 GHz
- Frequency range 30 MHz to 1 GHz
- Useful for disturbance power measurement & screening attenuation of cables
- Complies with CISPR 16-1-3
Com-Power CLA-150 Absorbing Clamp 30 MHz - 1 GHz
- Frequency Range: 30 - 1000 MHz
- Impedance: 50 Ohm
- Connector Type: BNC (f)
Com-Power CLCE-1032 RF Current Probe | 9 kHz – 1000 MHz
- Frequency range of 9 kHz to 1000 MHz
- Suitable for CISPR, MIL-STD-461, and DO-160
- Individual calibration
Com-Power CLCE-332 RF Current Probe | 9 kHz – 300 MHz
- Frequency range of 9 kHz to 300 MHz
- Suitable for CISPR, MIL-STD-461, and DO-160
- Individual calibration
PMM CLCE-400 Current Monitor Probe | 10 kHz – 400 MHz
- Frequency Range: 10 kHz to 400 MHz
- Suitable for CISPR, Mil-STD-461 & DO-160
Com-Power CLCE-438 RF Current Probe | 9 kHz – 400 MHz
- Frequency range of 9 kHz to 400 MHz
- Suitable for CISPR, MIL-STD-461, and DO-160
- Individual calibration
EMC Partner CN-BT6 Accessory for MIL3000 Test System
EMC Partner CN-MIG-BT5 Accessory for MIL3000 Test System
Teseq CN Series Coupling Network (CN) For IEC / EN 61000-4-16, DC to 150 kHz
- M4, 100 A, 690VAC
- Coupling networks designed for IEC / EN 61000-4-16
- M series for DC or AC power ports A series for communication ports, intended for unscreened, unbalanced lines
EMC Partner CN16T8 DC Coupling-Decoupling Network
- DC Line CDN for 8 Lines (4 pairs)
- ​EUT / AE connector (RJ45)
- IEC 61000-4-16 standard
PMM Cond-IS/10 Conducted Immunity System
- Generator 3010, 9 kHz – 1 GHz, -107 to +10 dBm
- Amplifier 6000N, 9 kHz – 230 MHz, 10/15 W
- ATT-25W, 6 dB Attenuator, 25 W max
PMM Cond-IS/10-CIP Conducted Immunity System
- Generator 3010, 9 kHz – 1 GHz, -107 to +10 dBm
- Amplifier 6000N, 9 kHz – 230 MHz, 10/15 W
- ATT-25W, 6 dB Attenuator, 25 W max
LeCroy CP150 Current Probe
- Current probe
- Compact design
- Broad bandwidth
Montena CS106 Pulse Generator
EMC Partner CS115REC Plug-in Module for MIG2000-6
- Current range into 100ohm: 1A up to 10A
- Rise time: < 2ns
- Fall time: < 2ns
EMC Partner CS116-10K10M Plug-in Module for MIG2000-6
- Current range into 100ohm: 0.02A up to 0.2A
- Frequency rang : 10 kHz to 10 MHz
- Damping: 4th peak 40 to 50%
California Instruments CSW5550 Programmable AC/DC Power Source, 5550VA
- Combination AC and DC Power Source
- 40-5,000Hz Output Frequencies
- Arbitrary and Harmonic Waveform Generation
Teseq CT 419-5 Current Transformer for IEC / EN 61000-4-19
- Coupling transformer designed for IEC/EN 61000-4-19
- Frequency range 2 kHz to 150 kHz
- 4 mm banana sockets
EM Test CWS 500N2 Continuous Wave Simulator
- Supports BCI testing as per various standard requirements
- Basic frequency range 9kHz up to 400MHz
- Extendable frequency range up to 1GHz
EM Test CWS 500N3 Low Frequency Simulator 10 Hz - 250 kHz
EM Test CWS 500N4 Conducted/Common-mode Disturbance Simulator, DC - 165 kHz
- Most compact equipment for common-mode disturbances as per IEC 61000-4-16
- Built-in LF signal generator and LF amplifier
- Sweep mode capability 10Hz to 165kHz
EM Test CWS 500N1 Continuous Wave Simulator, 80W
- Signal generator 9kHz to 1GHz
- Amplitude modulation: 1Hz to 3kHz (0% to 95%)
- Pulse modulation: 1Hz - 1kHz (10% to 90%)
EMC Partner DC-S17CL Accessory for MIL3000 Test System
Electro-Metrics EM-4310 Spike Generator
- 1.0 A at 115 VAC
- 0.5 A at 230 VAC
- Power Requirements: AC Power Sources: 115 VAC, 50-60 Hz, 1.0 A 230 VAC, 50-60 Hz, 0.5 A
PMM EMCL-20 10 kHz - 1GHz EM Injection Clamp | 20mm Aperture
- EM clamp for immunity testing of cables with up to 20 (35) mm diameter
- High coupling factor: less than 15 watts amplifier output power is required to obtain a test level of 10 V
- Calibration unit and calibration data are supplied with each instrument
PMM EMCL-35 10 kHz - 1 GHz EM Injection Clamp | 35mm Aperture
- EM clamp for immunity testing of cables with up to 20 (35) mm diameter
- High coupling factor: less than 15 watts amplifier output power is required to obtain a test level of 10 V
- Calibration unit and calibration data are supplied with each instrument
Montena EMP10K-5-500 Short Pulse Generator | 10 kV
- Short pulse generator
- Meets MIL-STD188-125-1/2 standards
- Generates short-duration double exponential current pulses
Montena EMP230K-2-23 NEMP Generator
- Technology and design scales up to a charging voltage of 1.2 MV.
- Interlock switch and automatic capacitor discharge for high safety requirements.
- Compact and robust construction.
Montena EMP25K-2-23 NEMP Generator | 50 kV/m for RS105
- Rise time of 2.3 ns ±0.5 ns
- Uses direct capacitive circuits or Marx technology
- Interlock switch for safety
Montena EMP300K-5-500 Short Pulse Generator | 350 kV
- Short pulse generator
- Evaluates conductive entries and protective devices per MIL-STD188-125-1/2
- Short double exponential current pulses up to 5 kA
Montena EMP80K-2-23-50 NEMP Generator
- Technology and design scales up to a charging voltage of 1.2 MV
- Interlock switch and automatic capacitor discharge for high safety requirements.
- Compact and robust construction.
Montena EMP80K-5-500 Short Pulse Generator 80 kV
- Short pulse generator
- Meets MIL-STD188-125-1/2 standards
- Short double exponential pulses
Fischer Custom Communications F-120-9A
- 7 dB attenuation between 100 kHz and 230 MHz when measured into a 50 ohms fixture
- Perform IEC 1000-4-6 testing with 20 watts or less of RF power
- Usable up to 200 watts
Fischer Custom Communications F-120615-1006-1 EM Injection Clamp
Fischer Custom Communications F-130A Bulk Current Injector Probe
- Broad band high efficiency injection probe
- Frequency range of 1 MHz to 700 MHz
- Insertion loss of 6 dB or less
Fischer Custom Communications F-16-1 Current Probe | 10Hz - 70MHz
Fischer Custom Communications F-203I-A-23mm EM Injection Clamp
Fischer Custom Communications F-203I-A-32mm EM Injection Clamp
Fischer Custom Communications F-33-2 Current Probe | 1kHz - 250MHz
- Compact probes with an external diameter of roughly 71 mm and an internal diameter of 32 mm
- Frequency spectrum from 1 kHz to 250 MHz
- BNC connector
Fischer Custom Communications F-72 Current Probe | 100Hz - 100MHz
EMC Partner Fx-DO-160-S19 Plug-in Module for MIG2000-6
- Modular construction allows for future expansion
- Clean reproducible waveforms
- Simple operation
Montena GP20-01-2 High Speed Pulse Generator 20kV, 400A
AH Systems ICP-621 Injection Current Probe | 10 kHz – 100 MHz
- Broad frequency range of 10 kHz to 100 MHz
- Individually calibrated
- Split type clamp-on design
AH Systems ICP-622 Injection Current Probe | 1 MHz – 500 MHz
- Broad frequency range of 1 MHz to 500 MHz
- Individually calibrated
- Split type clamp-on design
EMC Partner IMU C-SHORT Common Mode Short Duration Testing Extension
- IEC 61000-4-16 Standard
- Testing capabilities that find conducted immunity
- Common mode extension
EMC Partner IMU-MGS C Common Mode Extension
- IEC 61000-4-16 latest edition standard
- Frequency range of 0 Hz to 150 kHz
- Adjustable sweep time
EMC Partner IMU Slave Smart I1V1 External Module
- Voltage and current tests possible with one unit
- Exceeds maximum test levels in IEC 61000-4-19
- Integrated current source up to 25A
_17.png)
Prâna IP-DR250 Bulk Current Injection Probe
- Broadband (instantaneous single band) : 10 kHz – 400 MHz
- Frequency extension between 4kHz to 10kHz possible with limited power specifications
- Typical power: 500 W CW
Teseq ITS 6006 Radiated Immunity Test System 80 MHz - 6 GHz
- Integrated signal generator 80 MHz to 6 GHz
- Integrated RF switch network
- Multiple EUT monitoring options
Teseq (Schaffner) KEMA 801A Decoupling Clamp
- Decoupling Network/ RF attenuation clamp
- As specified in IEC/EN 61000-4-6
- Very efficient coupling
Teseq KEMZ 801AS 10 kHz - 1 GHz EM Clamp for IEC/EC 61000-4-6
- As specified in IEC/EN 61000-4-6
- Very efficient coupling
- Can be used on almost any cable
Teseq CDND M316-2 Coupling/Decoupling Network for Differential Mode
- Coupling networks designed for voltage test IEC/EN 61000-4-19
- Frequency range 2 kHz to 150 kHz
- 4 mm banana sockets
EMC-Partner MIG2000-6 Modular Impulse Generator
- Solid state impulse switch and solid state polarity change (no mechanical switch, no spark gaps or tubes) - advantages: low jitter, no high frequency switching noise,
- Microprocessor menu controlled, printer port and RS232 remote control
- Safety in accordance with VDE 0104 (safety circuit, connector for warning lamp)
EMC Partner MIL-MG3 Military Test System
- Positive
- Negative
- Electronic Switching
Teseq Mil-Std-461 CS114 10kHz - 400 MHz Conducted Susceptibility Test System
- Signal generation: NSG 4070-0
- Modulator: included in NSG 4070-0
- Power meter: 3x included in NSG 4070-0
EMC Partner MIL3-10K10M Plugin for MIL3000 Test System
EMC Partner MIL3-30M100M Plugin for MIL3000 Test System
EMC Partner MIL3-DO-160-S17 Plugin for MIL3000 Test System
EMC Partner MIL3-DO-160-S19 Plugin for MIL3000 Test System
EMC Partner MIL3-REC Plugin for MIL3000 Test System
EMC Partner MIL3-SPIKE Plugin for MIL3000 Test System
EMC Partner MIL3000 Military Test System
- Exceeds maximum test levels in MIL-STD-461
- One coupler for tests (CS115 & CS116)
- Test report data stored in MIL3000, accessible via USB or Ethernet
Solar Electronics 7399-3 Spike Generator
- Repetitive spikes up to 2500 V peak at two pulses per minute
- Single non-synchronous spike actuated by a pushbutton on the panel
- Sync functions provide for placing the spike on the power frequency waveform of 50, 60 or 400 Hz power lines; the spike can be moved to any point on the sine wave from 0 to 360°
Frankonia MTS-800 Magnetic-Field Low-Frequency Emission and Immunity Test System
- Frequency range for emission and immunity measurements: DC – 250 kHz
- 800W precision power amplifier, signal generator and spectrum analyzer in one compact unit
- All instruments may as well be used as stand-alone devices
California Instruments MX45 AC Power Source | 45 kVA, 3P
- Three Phase Mode Phase mode programming on MX30-3Pi and MX45-3Pi allows for a three-phase output
- Phase mode programming on MX30-3Pi and MX45-3Pi allows for a three-phase output
- High Power AC and DC Power Source Programmable AC and DC power for frequency conversion and product test applications
CA Instruments MX90 90kVA Power Source and Compliance Test System
- Combines AC/DC source and power analyzer functions
- AC, DC and AC+DC Operating Modes
- Powerful output transient generation
California Instruments MX Compliance Test System Series
- Direct PC bus access data acquisition system provides the required sampling rate and resolution to meet IEC 61000-4-7 measurement requirements and supports high speed data transfers, unlike competing
- PC based Harmonic and Flicker test software provides real-time full color data display updates and continuous PASS/FAIL monitoring.
- Automatic calculation of the maximum permissible system impedance Zsys, using the Zref and measured Flicker parameters, as required per EN/IEC 61000-3-11.
Teseq NSG200D with NSG203A Interference Simulator
- Line voltage: 220 / 240V - 50 Hz
- Option: 110V - 60 Hz
- Max rated current through line filter: 16 Amp
Teseq NSG 4060 Low Frequency Immunity Test System
- Signal generator and integrated power amplifier 15 Hz to 150 kHz
- Meets IEC / EN 61000-4-16 in combination with the Extension Unit
- Meets IEC / EN 61000-4-19 and other standards
Teseq NSG 4070C Test System for Conducted and Radiated Immunity
- Class A power amplifier module can be integrated for different applications:
- 35 W, 150 kHz to 230 MHz;
- 40 W, 10 kHz to 400 MHz;
Teseq NSG 4070C-110 Test System for Conducted and Radiated Immunity
- IEC/EN 61000-4-6
- 110W, 10kHz - 400MHz amplifier
- 4kHz - 1 GHz signal generator
Teseq NSG 4070C-80 Test System for Conducted and Radiated Immunity
- IEC/EN 61000-4-6
- 110W, 150kHz - 230MHz amplifier
- 4kHz - 1 GHz signal generator / power meter
Teseq NSG2070, IEC 61000-4-6 Test System, 100 kHz - 250 MHz
Teseq NSG 4070-75 Conducted & Radiated Immunity Test System
- Integrated signal generator 9kHz to 1GHz
- 4-channel power meter 9kHz to 1GHzAn advanced combination of signal generator and compact immunity test system.
- Integrated power amplifier module for different
Montena PG-C201 High Current Damped Oscillatory Wave Generator
- One single output for up to 12 test frequencies
- Frequency range 10 kHz – 100 MHz
- Control software running on a PC
Montena PG-CS115 Pulse Generator 5 kV
Montena PG1275 Surge Generator
- Standard: MIL-STD-1275D
- Transients supported: imported and exported spikes imported and exported surges
- imported and exported spikes
Montena PG1275E Surge Generator for MIL-STD 1275E
- Generator can be fully controlled by a computer through a RS232 or an USB interface
PMM BCICF-4 Injection Probe Calibration Fixtures
PMM BCICF-6-150 Injection Probe Calibration Fixtures
PMM F-120-9A Injection Probe
Montena POG-CS116-9 Transient Generator 10 kHz - 100 MHz
Montena PPG-E1-1200 Portable Pulse Generator for MIL-STD-188-125
- A wide operating range from 50 A to 1.2 kA
- Dedicated control software application for the configuration of the generator and the measurement equipment
- Battery powered, especially designed for tests onsite
PMM RAD-IS/3G-600 Radiated Immunity System
PMM RAD-IS/3G-600 Radiated Immunity System Series
PMM RAD-IS/3G-601 Radiated Immunity System
PMM RAD-IS/3G-602 Radiated Immunity System
California Instruments Tahoe | TA0045A1 Power Supply | 45 kVA
- Dual Voltage ranges that support over voltage testing on 480 V based systems
- Separate terminal blocks for single phase and 3 phase outputs
- High Power AC and DC Power Source
Tektronix TCP0020 Current Probe
- Easy-to-use design
- DC to >50 MHz bandwidth
- Core jaw diameter of 5 mm (0.2 in)
Tektronix TCP303
- Easy Current Measurements
- Probe Connects Directly to TDS Scope through TEKPROBE™ BNC Interface
- Split Core Construction for Easy Circuit Connection
Tektronix TCPA300 Current Probe Amplifier
- DC to 100 MHz maximum bandwidth
- Automatic control and onscreen scaling and units
- AC/DC input coupling
EMC Partner VERI-MIL3 Accessory for MIL3000 Test System
