Related Products
Keysight (Agilent) 11683A Power Meter Range Calibrator
- Calibration Functions: Outputs corresponding to meter readings of 3, 10, 30, 100, and 300 uW; 1, 3, 10, 30, and 100 mW
- Calibration Uncertainty: ±0.25% in all ranges
- Power: 100, 120, 220, or 240 Vac +5% -10%, 48 - 440 Hz, less than 10VA
Gigatronics 16934A Low Frequency Power Sensor
Bird 4022 Directional Power Sensor
- Cost-effective solution for maintaining critical RF systems
- Only 4 models are required to cover the frequency range of 1.8 MHz to 1 GHz and power range from 300 mW - 10 kW
- Full-Scale Accuracy ±3% for applications requiring accurate forward and reflected power measurement
Bird 4027A2M Precision Power Sensor 1.5 MHz - 2.5 MHz
Bird 4421 Multifunction Power Meter
- ±1% Accuracy - Accomplished through the use of sensors with an automatic frequency compensation scheme, where the error contributions due to directional coupler frequency response
- Wide Dynamic Range - The instrument will meet the full accuracy specification over a 35 dB dynamic range
- Excellent Measurement Repeatability - Typically <0.1%
Boonton 4500C Peak Power Analyzer
- Real-Time Power Processing™.
- Ultrafast trace acquisition and refresh rate.
- One button push for 15 automated power and time measurements.
Bird 5000-EX RF Digital Power Meter
- Handheld, lightweight design
- Frequency range of 2 MHz to 3.6 GHz
- User-friendly, back-lit display
Boonton 57006 Peak Power Sensor
- Fast measurement speed.
- Wide dynamic range (-50 dBm to +20 dBm).
- Calibration factors, linearity and temperature compensations data stored in EEPROM.
Boonton 59318 Peak Power Sensor
- Fast measurement speed.
- Wide dynamic range.
- Calibration factors, linearity and temperature compensations data stored in EEPROM.
Boonton 59340 Peak Power Sensors
- Fast measurement speed.
- Wide dynamic range (-70 dBm to +20 dBm).
- Calibration factors, linearity and temperature compensations data stored in EEPROM.
PMM 6630 RF Power Sensor
- 9 kHz to 3 GHz frequency range
- 100 nW to 1 W (-40 to +30 dBm) input range
- Excellent power linearity (0.2 dBm typical)
Gigatronics 80301A Series Standard Power Sensor
Gigatronics 80303A Standard Power Sensor
Gigatronics 80324A High Power Sensor
Gigatronics 80401A Power Sensor 10 MHz to 18 GHz
Gigatronics 80701A Modulated Power Sensor
Keysight 84814A Peak Power Sensor
- Frequency Range from 500MHz to 40GHz
- Outstanding measurement accuracy
- Automatic temperature sensing and correction
Keysight 8481A RF Power Sensor Type N
Keysight 8481B RF Power Sensor
Keysight 8481D Diode Power Sensor 10 MHz to 18 GHz
- Accurate average power measurements over -70 to -20dBm
- Compatible with EPM, EPM-P and P-series power meters, plus the E1416A
- Diode power sensing element
Keysight 8482A Power Sensor
Keysight 8482B Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
- Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
Keysight 8483A Power Sensor
- Thermocouple power sensing element
- 75 ohms input impedance power sensor
- Accurate average power measurements over -30 to +20 dBm
Keysight 8484A Power Sensor
- Excellent SWR for reducing mismatch uncertainty.
- Frequency range: 10MHz to 18GHz.
- 50 ohms impedance N (m) connector
Keysight 8487A Power Sensor
- Frequency range 50 MHz to 50 GHz
- Accurate average power measurements over -30 to +20 dBm
- Thermocouple power sensing element
Giga-tronics 8502A RF Peak Power Meter
- Internal self-calibration
- Gas-Plasma display
- Graph display mode for plot of pulse profile
Giga-tronics 8541 Universal Power Meter
- Power range of -70 dBm to +47 dBm (100 pW to 50 Watt)
- V Prop F input (BNC), analog output (BNC), blanking output (BNC), and trigger input (BNC)
- GPIB interface
Giga-tronics 8651A Single Channel Power Meter
Giga-tronics 8652A 10 MHz - 40 GHz Dual Channel Power Meter
Keysight 8990B RF Peak Power Analyzer | 50 MHz – 40 GHz
- 160 MHz video bandwidth
- 100 MSa/ sec continuous sampling with >1500 readings/ sec
- Frequency range of 50 MHz to 40 GHz (sensor dependent)
Keysight E4412A E-Series Wide Dynamic Range Power Sensor
- Fast measurement speed, up to 400 readings per second with the E4416A
- Wide dynamic range (-70 dBm to +20 dBm)
- Calibration factors, linearity ana temperature compensations data stored in EEPROM
Keysight E4416A Single Channel Power Meter
- 20 Msample/s per second sampling rate for reliable continuous and single shot measurements on wide bandwidth signals
- Time-gated and free run power measurements
- Free Analyzer Software software for complete pulse and statistical analysis, software is located In the Library
Keysight E4417A EPM-P Series Dual-Channel Power Meter
- 20 Msample/s per second sampling rate for reliable continuous and single shot measurements on wide bandwidth signals
- Time-gated and free run power measurements
- Free 'Analyzer Software' software for complete pulse and statistical analysis, software is located 'In the Library'
Keysight E4418A EPM Power Meter
- Fast measurement speed (up to 200 readings per second, over the GPIB, with E-series sensors)
- Speed improvement of x2 using the 8480 series power sensor (compared to 437B)
- No range-switching delays with 8480 series sensors, and only one fast-range switch point with E-series sensors
Keysight E4418B EPM RF Power Meter
- Fast measurement speed (up to 200 readings per second, over the GPIB, with E-series sensors)
- Speed improvement of x2 using the 8480 series power sensor (compared to the 437B)
- No range-switching delays with 8480 series sensors, and only one fast-range switch point with E-series sensors
Keysight E4419B EPM Dual-Channel Power Meter
- Frequency Range: 9kHz to 110GHz, sensor dependent
- Power Range: -70dBm to +44dBm (100pW to 25W), sensor dependent
- Power Sensors: Compatible with all 8480 series and HP E series sensors
Keysight E9300 Power Sensor | 10 MHz to 18 GHz
- Frequency range of 10 MHz to 18 GHz
- Dynamic range of -60 to +20 dBm
- Operation with E4418A/B, E4419A/B, E4416A and E4417A power meters
Keysight E9304A E-Series Average Power Sensor
- Measure transmitter power and receiver sensitivity at Very Low Frequency (VLF) to microwave frequencies...
- High maximum power specification
- Low SWR for reducing mismatch uncertainty
Keysight E9323A E-Series Peak/Average Power Sensor
- Modulation Bandwidth of 5MHz
- Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
- Wide dynamic range
Keysight E9327A Peak and Average Power Sensor
- 5 MHz video bandwidth, ideal for E-CDMA and cdma2000 applications
- Fast measurement speed, up to 1000 corrected readings per second, via the GPIB
- Wide dynamic range
Keysight ECP-E26A CW Power Sensor
- Fast measurement speed, up to 400 readings per second with the.
- E4416A
- Wide dynamic range (-70dBm to +20dBm)
Keysight EPM-441A Single-Channel Power Meter
- Fully compatible with the HP 8480 series of power sensors and the ECP
- Designed for bench and automatic test equipment (ATE) use, the EPM-441A
- up to 200 readings per second with ECP series sensors
Rohde Schwarz FSH-Z18 Power Sensor
- True RMS value of measured signal irrespective of signal waveform
- Power measurements from 10 MHz to 18 GHz
- Measurement range –67 dBm to + 23 dBm
Anritsu MA24002A Power Sensor | 10MHz - 18GHz
- Part of the Anritsu MA24000A Series
- True-RMS detection enables accurate average power measurements of any signal type
- 50 dB dynamic range
Anritsu MA24004A Power Sensor | 10MHz - 40GHz
- Part of the Anritsu MA24000A Series
- True-RMS detection enables accurate average power measurements of any signal type
- 50 dB dynamic range
Anritsu MA24005A Power Sensor | 10MHz - 50GHz
- Part of the Anritsu MA24000A Series
- True-RMS detection enables accurate average power measurements of any signal type
- 50 dB dynamic range
Anritsu MA2442D Power Sensor | 10MHz - 18GHz
- Wide dynamic range sensors (-67 dBm to +20 dBm)
- Accurate CW average power measurements
- Wide frequency coverage from 10 MHz to 18 GHz
Anritsu MA2444A High Accuracy Sensor 10 MHz to 40 GHz
Anritsu MA2444D Power Sensor | 10MHz - 40GHz
- Wide dynamic range sensors (-67 dBm to +20 dBm)
- Accurate CW average power measurements
- Wide frequency coverage from 10 MHz to 40 GHz
Anritsu MA2445A Power Sensor, High Accuracy Diode
Anritsu MA2445D Power Sensor | 10MHz - 50GHz
- Wide dynamic range sensors (-67 dBm to +20 dBm)
- Accurate CW average power measurements
- Wide frequency coverage from 10 MHz to 50 GHz
Anritsu MA2473A Power Sensor 10 MHz - 32 GHz
Anritsu ML2438A Power Meter
- Speed and dynamic range
- Fast thermal sensors
- GPIB speed
Keysight N1912A P-Series Dual Channel Power Meter | 50 MHz - 18 GHz
- 30 MHz video bandwidth
- Single shot real time capture at 100 Msamples/s per second
- Key Measurements: - peak, average, peak-to-average ratio, rise time, fall time and pulse width
Keysight N1914A EPM Series Dual-Channel Power Meter | 9 kHz - 110 GHz
- Frequency range of 9 kHz to 110 GHz (sensor dependent)
- Wide dynamic range of -70 to +44 dBm (sensor dependent)
- Speed improvement by 2X for E-Series sensors: up to 400 readings/sec
Keysight N1921A P-Series | Wideband | 50 MHz – 18 GHz
- Zero and calibrate while connected to the DUT
- -35 dBm to +20 dBm wide dynamic range for peak power measurements
- Calibration factors, linearity, temperature and bandwidth correction data stored in EEPROM
Keysight N1922A P-Series Wideband Power Sensor | 50 MHz to 40 GHz
- Zero and calibrate while connected to the DUT
- -35 dBm to +20 dBm wide dynamic range for peak power measurements
- Calibration factors, linearity, temperature and bandwidth correction data stored in EEPROM
Keysight N1924A Wideband Power Sensor, 50 MHz to 40 GHz
- Zero and calibrate while connected to the DUT
- -35 dBm to +20 dBm wide dynamic range for peak power measurements
- Calibration factors, linearity, temperature and bandwidth correction data stored in EEPROM
Keysight N8480 Series Power Sensors
Keysight N8487A Thermocouple Power Sensor
- EEPROM to store cal factors eliminates manual entry
- Wide frequency range from 50 MHz to 50 GHz
- Wide dynamic range from -35 dBm to +20 dBm
Rohde & Schwarz NRP-Z22 Three-Path Diode Power Sensor
- Measurement range: -57 dBm to +33 dBm (2 nW to 2 W)
- Frequency range: 10 MHz to 18 GHz
- N connector
Rohde & Schwarz NRP6A
- Measurement range: -70 dBm to +23 dBm
- Frequency range: 8 kHz to 6 GHz
- N connector
Rohde & Schwarz NRVS Power Meter
- Fast power, level and voltage measurements
- Intelligent NRV-Z probes and URV5-Z sensors: plug and play
- IEC/IEEE-bus interface
Keysight Q8486A Thermocouple Waveguide Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- 50 MHz calibration port
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
Anritsu PSN50 High Accuracy Power Sensor
- Cal Factor Correction
- Remove noise and improve overall accuracy for low level signals (<-20 dBm)
Keysight R8486A Thermocouple Waveguide Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- 50 MHz calibration port
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
Boonton RTP4006 Real-Time True Average Power Sensor
- 4 kHz to 6 GHz and 10 MHz to 6 GHz sensors.
- -60 dBm to +20 dBm dynamic range.
- 175 kHz video bandwidth for pulse profiling.
Boonton RTP5006 Real-Time Peak Power Sensors
- Up to 195 MHz video bandwidth with 3 ns rise time.
- Real-Time Power Processing™ technology with zero measurement dead time.
- 100,000 measurements per second.
Boonton RTP5318 Real-Time Peak Power Sensors
- Up to 70 MHz video bandwidth with 5 ns rise time.
- Real-Time Power Processing™ technology with zero measurement dead time.
- 100,000 measurements per second.
Keysight U2001A USB Power Sensor 10 MHz - 6 GHz
- Frequency range of 10 MHz to 6 GHz
- Extended frequency of 3 MHz to 6 GHz with option H3
- Wide dynamic range of -60 to +25 dBm sensor option dependent
Keysight U2002A-H26 USB Power Sensor
- Frequency range of 50 MHz to 24 GHz
- Extended frequency of 10 MHz to 26.5 GHz with option H26.
- Wide dynamic range of -60 to +20 dBm
Keysight U2022XA
- Frequency range of 50 MHz to 40 GHz
- Wide dynamic range of -30 to +20 dBm (peak/gated), -45 dBm to 20 dBm (average only mode)
- 30 MHz video bandwidth
Keysight U2054XA USB Average Power Sensor
- Frequency range of 10 MHz – 40 GHz
- USB connectivity with wide dynamic range of -70 to +20 dBm
- Fast real-time measurement
Keysight U8488A-100 USB Thermocouple Power Sensor
- Frequency range of 10 MHz to 67 GHz
- Fastest measurement speed for thermocouple sensor, > 900 readings/s (free run/fast buffer mode)
- Best-in-class power linearity of less than 0.8%
Keysight V3500A Handheld RF Power Meter
- Broad 10 MHz to 6 GHz frequency range enables use in a wide variety of applications
- Wide dynamic range of -60 dBm to +20 dBm
- Integrated power sensor eliminates the need to carry a separate power sensor
Keysight W8486A Waveguide Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- 50 MHz calibration port
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
Werlatone WPM11101 RF IN-Line Power Meter
- Local and/or remote monitoring
- Forward power reading/monitoring (watts or dbm)
- Reverse power reading/monitoring (watts or dbm)
Boonton RTP5000 Series Real-Time Peak Power Sensors
- RTP5518: Frequency Range | 50 MHz - 18 GHz
- RTP5540: Frequency Range | 50 MHz - 40 GHz
- RTP5518/RTP5540: Dynamic Range: Pulse | -40 … +20 dBm
