AE Techron 8704 Linear Power Amplifier
The AE Techron 8704 Linear Power Amplifier is part of the AE Techron 8700 Series of high-power amplifiers. The 8704 model has a maximum continuous output current of 60 ARMS, a surge rating of 2X power at up to 400 VP or 150 A, and more. The AE Techron 8704 has AC, DC, and AC + DC operating modes.
| Model | 8704 |
| Maximum Continuous Output Current | 60 ARMS |
| Surge Rating | 2X power at up to 400 VP or 150 A |
| Apparent Power Rating | Up to 5X continuous power rating at up to 400 VP or 150 A |
| Supply Voltage | Single-phase, 208 V ±10%, 30 A, 50/60 Hz; 230 V / 240 V ±10%, 30 A version available |
| Operating Modes | AC, DC and AC + DC |
| Frequency, AC Mode Output (-3 dB) | DC - 250 kHz |
| Cooling | Internal forced-air fans |
| Dimensions (H x W x D) | 5.25 x 19.0 x 25.26 in. (13.34 x 48.26 x 64.16 cm) |
| Weight | Approximately 84 lb. (38.1 kg) |
- Power levels up to 5X rated power when driving reactive loads
- High power efficiency and density
- Ultra-wide bandwidth
- Part of the 8700 Series
SKU: AETE-8704
