Advanced Amplifiers AA-1826G-10 Solid State Amplifier | 18.0 - 26.5 GHz, 10 W

Advanced Amplifiers AA-1826G-10 Solid-State Amplifiers work over a frequency range of 18.0 - 26.5 GHz and can generate 10 W of power. They have a 40 dB minimum power gain and operate with a 100 - 240 VAC single-phase (220 W) input. These devices are lightweight and have a low-profile (2U) build, which allows for easy transportation and more space for additional test equipment.

Reach out to ATEC today for affordable AA amplifier rentals.

Product Info Related Products

Parameter	Specification	Notes
Operating Frequency Range	18.0 - 26.5 GHz
Power Output CW	10 Watt Min
Power Output @ PldB	10 Watt Typ	Few frequency spots that could be marginal 10W
Power Gain	40 dB Min
Power Gain Flatness	4.0 dB p-p Max	Constant input power
Input Return Loss	10 dB Min	Relative to 50 Ohm
2-Tone Intermodulation (IMD)	-30 dBc Typ	30dBm/Tone, Δ = 1MHz
Harmonics	-20 dBc Typ	At rated Pout
Spurious	60 dBc Min	Non-harmonics
Operating Voltage	100 - 240 VAC
Power Consumption	220 Watt Max
Max Input Power Protection	+3 dBm	10 Sec without damage
Load VSWR Protection	5:1	<1 minute at rated Pout
Operating Ambient Temperature	0 to +50 °C
Storage Temperature	-40 to +85 °C
Relative Humidity	5 to 95 %	Non-condensation
Dimensions W x H x D	430 x 88 x 562 mm	2U
Weight	9 kg.
RF Connectors In/Out	2.9 mm (K / air type) Female	Front Panel Standard
AC Power / Interface Connector	IEC 60320-C14 / 9-Pin D-Sub
Cooling	Built in Fan Cooling
OPTIONAL: Digital Monitor & Control FWD, REV, VSWR, GAIN, ALC, V & I, TEMP	Ethernet RJ-45 TCP/IP, RS422/485 Optional GPIB Interface	Remote Bluetooth application
