RF System Lab VJ-3 Series ViewTech Videoscopes
The RF System Lab VJ-3 Series ViewTech Videoscopes are designed for accuracy and responsiveness. This instrument comes with useful features such as a side view, retrieval hook, and magnet. The RF System VJ-3 Series provides ideal devices for aircraft and power generation maintenance teams who need to quickly and easily inspect turbine blades, cooling tubes, and combustion chambers.
The RF System Lab VJ-3 Series eliminates the need for a costly and time-consuming engine and system tear-down. Compatibility with rechargeable Li-ion batteries for 4-hour run times keep projects going while being mindful of energy consumption.
The RF System Lab VJ-3 6 x 8 and 6.00 mm Articulating Video Borescopes are part of this series.
| VJ-3 (3.9 mm) | VJ-3 (6.0 mm) | |
| Diameter | 3.9 mm | 6.0 mm |
| Length | 1.5 or 3.0 m | 1.5, 3.0, 5.0, or 8.0 m |
| Depth of Field | 7.0 - 80.0 mm | 7.0 mm+ |
| Field of View | 130° x 98° | 100° x 75° |
| Resolution | 640 x 480 | 640 x 480 |
- Full color IPS anti-glare LCD display
- High-capacity SD storage and USB connectivity
- Joy-stick controlled 360° camera articulation
- Video start-stop
- Ergonomic pistol grip design
- Rechargeable li-ion battery (4 hour runtime)
- On-board image processing
- 4x digital zoom
- Image capture trigger
- Tungsten braided IP 67 insertion tube
- Up to 20,000 Lux, 6-stage LED illumination
