Tettex FRA 5311 Sweep Frequency Response Analyzer
- Measures according to IEC 60076-18 and IEEE C57.149
- Measures magnitude (dB), phase angle (°), impedance (Ω), admittance (S), and ratio
- High signal to noise ratio due to output voltage up to 11 Vpp at 50 Ω
OMICRON Bode 100 Vector Network Analyzer 1 Hz - 40 MHz
- Swept S-parameters in the 50 system
- Reflection coefficient and return loss
- Insertion loss of filters
Tettex Instruments FRA 5310 Transformer Frequency Response Analyzer
- High measurement reliability and reproducibility due to active probes design from 10Hz - 10MHz.
- High signal-to-noise ratio due to output voltage 1V peak to peak (24V)
- Ease of use due to automated test software, large color touch screen interface and remote start button.
OMICRON FRANEO 800 Sweep Frequency Response Analyzer
- Extremely small and compact device
- Innovative connection technique
- Short measurement times
Megger FRAX 101 Sweep Frequency Response Analyzer
- Smallest and most rugged FRA instrument in the industry
- Highest possible repeatability by using reliable cable practice and high-performance instrumentation
- Fulfills all international standards for SFRA measurements
Megger FRAX150 Sweep Frequency Response Analyzer
- Highest dynamic range and accuracy in the industry
- Built-in PC with powerful backlit screen for use in direct sunlight
- Highest possible repeatability by using reliable cable practice and high-performance instrumentation
Doble M5300 Sweep Frequency Response Analyzer
Doble M5400 Sweep Frequency Response Analyzer
- 1000 points (Default)
- Up to 1800 points (Extended Range)
- Instrument sends excitation signals to transformer and measures the returning signals across a broad frequency range
Doble M5500 Sweep Frequency Response Analyzer
- 1045 points (Default)
- Up to 5000 points (Extended Range)
- Lightweight and rugged portable test instrument
Omicron Bode 500 Vector Network Analyzer
- 10 mHz - 450 MHz
- -50 dBm - 16 dBm
- 3.52 µHz
