Konica Minolta CS-3000HDR Spectroradiometer

The Konica Minolta CS-3000HDR is a spectroradiometer designed for display measurement, luminance, and chromaticity analysis. It features a 0.0001 to 100,000 cd/m² luminance range, 1°, 0.2°, and 0.1° measurement angle switching, and a 5 nm or less spectral resolution. The unit supports USB 2.0 and RS-232C communication, fast measurement speeds as low as 0.041 seconds per sample, and synchronization with display refresh rates. It is used for OLED, LCD, MicroLED, projector calibration, and automotive display testing.

Product Info Related Products

Measurement Wavelength Range	380 - 780 nm
Wavelength Resolution	0.9 nm/pixel
Display Wavelength Interval	1.0 nm
Measurement Angle Options	1°, 0.2°, 0.1° (powered switching)
Luminance Range with Guaranteed Accuracy	0.0001 - 100,000 cd/m²
Chromaticity Accuracy at 0.05 cd/m²	x: ±0.0015, y: ±0.001 / u': ±0.0014, v': ±0.0006
Communication Interfaces	USB 2.0, RS-232C (up to 921,600 bps)
Integration Time	0.005 to 92 seconds (Normal mode), 0.005 to 16 seconds (Fast mode)
Operating System Compatibility	Windows 10/11, macOS Monterey/Big Sur/Catalina
Power Supply	Dedicated AC Adapter (100-240V, 50/60Hz)
Dimensions (W x H x D)	158 × 262 × 392 mm
Weight	Approx. 7.0 kg

High precision
Wide dynamic range of measurement
1°, 0.2°, 0.1° powered measurement angle switching
Reducing measurement time
- High-speed modes
- Intelligent dark function
- Emission frequency detection/setting function

SKU: MINO-CS-3000HDR

Konica Minolta CS-3000HDR Spectroradiometer
