Keysight CX1102A Dual Channel Current Sensor

The Keysight CX1102A Dual Channel Current Sensor is a current sensor accessory that couples two channels on a CX3300 system and tests over a 100 dB wide dynamic range with a single measurement. A Keysight CX1102A unit measures from 40 nA to 1 A and up to ±12 V with a 100 MHz maximum bandwidth. Keysight CX1102A current sensors allow engineers to view both waveforms at once on a CX3300 device such as the Keysight CX3324A. This simplifies the analysis of wide dynamic range current waveforms, like those found in low power wireless devices and low power microcontrollers which fluctuate between active and standby states.

The Keysight CX1102A serves as a current sensor accessory to the Keysight CX3324A Current Waveform Analyzer.
