Keithley 6517B Electrometer/High Resistance Meter
The Keithley 6517B Electrometer/High Resistance Meter is the worldwide research laboratory standard for sensitive measurements. Designed with top-notch low level measurement expertise, Keithley 6517B electrometers provide reliable measurements of current levels down to 10 aA (10×10–18 A), charge levels down to 1 fC, and the highest resistance measurements available up to 1018 Ω. The Keithley 6517B is also capable of measuring the largest voltage range—up to 200 V—with an input impedance exceeding 200 TΩ. All this performance is built into an instrument that operates as simply as a digital multimeter.
| Overrange Indication | Display reads “OVERFLOW” for readings >105% of range. The display reads “OUT OF LIMIT” for excesive overrange conditions |
| Ranging | Automatic or manual |
| Conversion Time | Selectable 0.01 PLC to 10 PLC |
| Maximum Input | 250 V peak, DC to 60 Hz sine wave; 10 sec. per minute maximum on mA ranges |
| Maximum Common Mode Voltage | Electrometer, 500 V peak; V Source, 750 V peak |
| Isolation (Meter COMMON to chassis) | >1010 Ω, <500 pF |
| Input Connector | Three lug triaxial on rear panel |
| 2 V Analog Output | 2 V for full range input. Non-inverting in Volts mode, inverting when measuring Amps, Ohms, or Coulombs; output impedance 10 kΩ |
| Preamp Output | Provides a guard output for Volts measurements. Can be used as an inverting output or with external feedback in Amps and Coulombs modes |
| External Trigger | TTL compatible External Trigger and Electrometer Complete |
| Guard | Switchable voltage guard available |
| Digital I/O and Trigger Line | Available, see manual for usage |
| EMC | Conforms to European Union Directive 89/336/EEC, EN 61326-1 |
| Safety | Conforms to European Union Directive 73/23/EEC, EN 61010-1 |
- Measures resistances up to 1018 Ω
- 10 aA (10×10–18 A) current measurement resolution
- Complete hardware-software solution for ASTM D257 high resistivity measurements with the 6517B, 8009 Resistivity Test Fixture, and the KickStart High Resistivity Measurement Application
- <3 fA input bias current
- 6½-digit high accuracy measurement mode
- <20 μV burden voltage on the lowest current ranges
- Voltage measurements up to 200 V with >200 Ω input impedance
- Built-in ±1000 V voltage source
- Unique alternating polarity voltage sourcing and measurement method for high resistance measurements
- Built-in test sequences for four different device characterization tests, surface and volume resistivity, surface insulation resistance, and voltage sweeping
- Optional plug-in scanner cards for testing up to ten devices or material samples with one test setup
- GPIB and RS-232 interfaces
- Ultra-sensitive ammeter with current measurement from 10 aA to 20 mA
- Highest impedance voltmeter with voltage measurement from 1 μV to 200 V
- Ultra-high range ohmmeter with resistance measurement from 1 Ω to 1018 Ω
- Sensitive coulombmeter with charge measurement from 1 fC to 2 μC
SKU: KEIT-6517B
