Advanced Amplifiers AA-24G-4KWP Pulsed RF Amplifier
- Frequency Range: 2.0 - 4.0 GHz
- Output: 4kW, 66dBm
- Duty Cycle: 6%, Pulse Width: up to 100μs
IFI T2618-10 TWT Amplifier 18 GHz - 26.5 GHz, 10 Watt
- Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
- Status Indicators: Power On, Standby, RF On/Operate
- Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent
Advanced Amplifiers AA-618G-300-T TWT Pulse Amplifier
- 6.0 - 18.0 GHz
- 300 W
- 54 dB min
IFI PT42-5KW Pulse Amplifier
- Frequency Range: 2.0 - 4.0GHz
- Output: 5kW, 67dBm
- Duty Cycle: 6%, Pulse Width: 0.1 - 100μs
Advanced Amplifiers AA-12G-4KW-PT TWT Pulse Amplifier
- Frequency Range: 1.0 - 2.0GHz
- Output: 4kW, 66dBm
- Duty Cycle: 6%, Pulse Width: 0.1 - 100μs
IFI T82-500 TWT Amplifier, 2 - 8GHz, 500W
- Solid state power supply
- Instantaneous broadband frequency range
- Modular design, rugged construction, force air cooling
Amplifier Research 60S1G6 Microwave Solid State Amplifier 0.7 - 6.0 GHz, 60W
- 700 MHz - 6 GHz
- 60 W
- CW Amplifier
CPI PTC6358 Pulse TWT Amplifier
- Frequency Range: 7.5 - 18GHz
- Output: 2kW (typ.), 63dBm
- Duty Cycle: 6%, Pulse Length: 0.2 - 100μs
IFI T186-60 TWT Amplifier 6 GHz - 18 GHz, 60W
- Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
- Status Indicators: Power On, Standby, RF On/Operate
- Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent
Advanced Amplifiers AA-618G-2KW-PT High Power TWT Pulse Amplifier
- Frequency Range: 6.50 - 18.0GHz
- Output: 2kW, 63dBm
- Duty Cycle: 6%, Pulse Width: 0.1 - 100μs
Advanced Amplifiers AA-48G-4KWP Solid-State Amplifier
- Frequency Range: 4.0 - 8.0GHz
- Output: 4kW, 66dBm
- Duty Cycle: 10%, Pulse Width: Up to 100μs
Exodus AMP2065B Solid State RF Amplifier | 6 GHz - 18 GHz, 300 W
- Class AB linear GaN hybrid design
- Instantaneous ultra-wide bandwidth
- Solid-state TWT replacement
IFI PT825-2KW Pulse TWT Amplifier
- Frequency Range: 2.5 - 8.0GHz
- Output: 2kW, 63dBm
- Duty Cycle: 6%, Pulse Width: 0.1 - 100μs
IFI S31-500 Solid State RF Power Amplifier 800 MHz - 3 GHz, 500 Watts
- VSWR Reflected Power Protection, the unit operates without damage or oscillation into any magnitude of phase or load impedance, Open and Short Circuit Protection.
- Alternate Prime Power (specify at time of order)
- GPIB IEEE 488 and RS232 Remote Control
Advanced Amplifiers AA-118G-20 Solid State Amplifier
- 1.0 - 18.0 GHz
- 20 W
- 43 dB min
IFI T42-200 TWT Amplifier 2 GHz - 4 GHz, 200 Watt
- Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
- Status Indicators: Power On, Standby, RF On/Operate
- Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent
IFI S188-20 Solid State RF Amplifier 8 - 18 GHz, 20W
- Total/Operate Elapsed Time Metering in hours
- RF Safety Interlock
- Forward/Reflected Power Indication simultaneously on Front Panel display
IFI T-1000 Series High Power, RF Microwave, TWT Amplifiers
- Input/output Impedance: 50 ohms
- RF Input/ Sample Connectors: Type N Female, unless specified otherwise
- RF Output Connector: Type 716 Female up to 7.5 GHz, 4 – 8 GHz is WRD350 8 – 12 GHz is WR90, 12 – 18 GHz is WR62, 7.5 – 18 GHz is WRD750, 6.5 – 18 GHz is WRD650 Other
IFI T82-250 TWT Amplifier 2 GHz - 8 GHz, 250 Watt
- Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
- Status Indicators: Power On, Standby, RF On/Operate
- Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent
Quarterwave 9108/96506-J12J18 TWT Pulse Amplifier
- Frequency Range: 12 – 18GHz
- Output: 3.4kW, 65dBm
- Duty Cycle: 6%, Pulse Width: 0.1 - 100μs
_24.jpg)
Advanced Amplifiers AA-12G-8KWP Pulsed Solid-State RF Amplifier
- Frequency Range: 1.0 - 2.0GHz
- Output: 8kW, 69dBm
- Duty Cycle: 6%, Pulse Width: up to 100μs
Logimetrics A330/C TWT Amplifier, 4 GHz - 8 GHz, 20 Watts
- 4 GHz - 8 GHz
- 20 W
- CW Amplifier
Advanced Amplifiers AA-618G-20 Solid State Amplifier
- 6.0 - 18.0 GHz
- 20 W
- 43 dB min
IFI T188-500 High Power Amplifier | 7.5 – 18 GHz, 500 W
- Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
- Status Indicators: Power On, Standby, RF On/Operate
- Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent
IFI T84-50 TWT RF Microwave Power Amplifier
- Digital Display Monitors: Collector Current, Collector Voltage, Helix Current, Helix Voltage, Forward RF Power, Reflected RF Power, Filament Hours, Beam Hours
- Status Indicators: Power On, Standby, RF On/Operate
- Faults: Helix Overcurrent, VSWR Overload, Thermal Overloads, Air Flow, Collector Overcurrent
