| Test time |
Copper: 7 sec to 1000 MHz, 23 sec to 3000 MHz
Fiber: 14 sec dual-wavelength, one direction. 28 sec, dual-wavelength, bi-directional |
| Frequency |
Up to 3000 MHz |
| Wiremap distance to fault display resolution |
10 cm / 3.9 in |
| Length measurement |
Copper - Measurement range: 0-600m/0-1,960ft Fiber - Measurement range 0-10km/0-32,808ft |
| DC resistance |
0.02 - 200 ohms |
| Propagation delay |
1ns - 1s |
| Operating temperature |
0°C to 45°C |
| Languages |
Chinese, English, French, German, Italian, Portuguese, Russian, and Spanish |
Dimensions
(H x W x D) |
10 x 5 x 2 in (25.4 x 12.7 x 5.3 cm) |
| Weight |
Display: 2.35 lb. (1.1 kg)
Remote: 2.30 lb. (1.0kg) |
