Com-Power CLCE-1032 RF Current Probe | 9 kHz – 1000 MHz
The Com-Power CLCE-1032 RF Current Probe has a frequency range of 9 kHz to 1000 MHz, Type N Female connector, and an outside diameter of 2.83 inches. Used with a spectrum analyzer or EMI receiver, this model is ideal for CISPR, MIL-STD-461, and DO-160 standards. The CLCE-1032 has a rugged and user-friendly design. Reach out today to learn more about this RF current probe and similar models.
Model | CLCE-1032 |
Frequency Range | 9 kHz – 1000 MHz |
Window (Aperture) Inside Diameter | 1.26 in (32 mm) |
Outside Diameter | 2.83 in (72 mm) |
Connector | Type N Female |
Maximum Primary Current (DC – 60 Hz) | 150 A |
Maximum Primary Current (400 Hz) | 135 A |
Maximum Primary Current (RF) | 2 A |
Pulse (8/20 µs) | 500 A |
Weight | 0.275 lb. (0.125 kg) |
- Frequency range of 9 kHz to 1000 MHz
- Suitable for CISPR, MIL-STD-461, and DO-160
- Individual calibration
- Rugged design
- CISPR 22
- CISPR 32
- DO-160
- MIL-STD-461
