Chroma 61511 AC/DC Power Source, 12kVA

The 61511/61512/61611/61612 AC source models provide the (Master-Slave) parallel operation function, which enable users to extend the AC source power output ability by connecting AC sources in parallel. The maximum allowable number of AC source implemented for the parallel operation is 5 units. Therefore, users can achieve a maximum power output up to 90KVA by combining 5 units of assorted AC source of 18KVA in (Master-Slave) parallel operation mode. The user could also use A615103 Power Stage as an alternative cost effective solution for the parallel operation, by implementing it as slave unit.

Product Info Related Products

Output Phase	1 or 3 selectable
Output Rating-AC
Power	12kVA
Each Phase	4 kVA
Voltage
Range	0~150V/0~300V
Accuracy	0.2%+0.2%F.S.
Resolution	0.1 V
Distortion *1	0.3% @50/60Hz , 1%@15~1kHz,1.5%@>1kHz
Line regulation	0.1%
Load regulation *2	0.2%
Temp. coefficient	0.02% per degree from 25°
Max Current (1-phase mode)
RMS	96A/48A
Peak (CF=4)	384A / 192A
Max Current (each phase in 3-phase mode)
RMS	32A / 16A
Peak (CF=4)	182A / 64A
Frequency
Range	DC, 15-1.5kHz
Accuracy	0.15%
Phase
Range	0 ~ 360°
Resolution	0.3°
Accuracy	<0.8°@50/60Hz
DC Output (1-phase mode)
Power	6kW
Voltage	212V / 424V
Current	48A / 24A
DC Output (3-phase mode)
Power	2kW
Voltage	212V / 424V
Current	16A / 8A
Input AC Power (each phase)
AC type	3-phase, Delta or Y connecting
Voltage range *3	190-250V (Delta: L-L, Y: L-N)
Frequency range	47-63 Hz
Max. current	Delta: 80A Y: 70A
Measurement
Voltage
Range	150V / 300V
Accuracy	0.2%+0.2%F.S.
Resolution	0.1 V
Current
Range	128 /32/8 A peak
Accuracy (rms)	0.4%+0.3%F.S
Accuracy (peak)	0.4%+0.6%F.S.
Resolution	0.1 A
Power
Accuracy	0.4%+0.4% F.S
Resolution	0.1 W
Dimensions (H x W x D)	1163 x 546 x 700 mm / 45.78 x 21.5 x 27.56 inch *5
Weight	242.4 kg / 533.92 lbs
