Boonton RTP5000 Series Real-Time Peak Power Sensors
- RTP5518: Frequency Range | 50 MHz - 18 GHz
- RTP5540: Frequency Range | 50 MHz - 40 GHz
- RTP5518/RTP5540: Dynamic Range: Pulse | -40 … +20 dBm
Keysight W8486A Waveguide Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- 50 MHz calibration port
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
Keysight 8481D Diode Power Sensor 10 MHz to 18 GHz
- Accurate average power measurements over -70 to -20dBm
- Compatible with EPM, EPM-P and P-series power meters, plus the E1416A
- Diode power sensing element
Keysight N1922A P-Series Wideband Power Sensor | 50 MHz to 40 GHz
- Zero and calibrate while connected to the DUT
- -35 dBm to +20 dBm wide dynamic range for peak power measurements
- Calibration factors, linearity, temperature and bandwidth correction data stored in EEPROM
Gigatronics 80301A Series Standard Power Sensor
Keysight R8486A Thermocouple Waveguide Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- 50 MHz calibration port
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST) millimeter-wave sensor calibration
Keysight 8483A Power Sensor
- Thermocouple power sensing element
- 75 ohms input impedance power sensor
- Accurate average power measurements over -30 to +20 dBm
Keysight 84814A Peak Power Sensor
- Frequency Range from 500MHz to 40GHz
- Outstanding measurement accuracy
- Automatic temperature sensing and correction
Keysight N1912A P-Series Dual Channel Power Meter | 50 MHz - 18 GHz
- 30 MHz video bandwidth
- Single shot real time capture at 100 Msamples/s per second
- Key Measurements: - peak, average, peak-to-average ratio, rise time, fall time and pulse width
Gigatronics 80401A Power Sensor 10 MHz to 18 GHz
Keysight E4418B EPM RF Power Meter
- Fast measurement speed (up to 200 readings per second, over the GPIB, with E-series sensors)
- Speed improvement of x2 using the 8480 series power sensor (compared to the 437B)
- No range-switching delays with 8480 series sensors, and only one fast-range switch point with E-series sensors
Keysight (Agilent) 11683A Power Meter Range Calibrator
- Calibration Functions: Outputs corresponding to meter readings of 3, 10, 30, 100, and 300 uW; 1, 3, 10, 30, and 100 mW
- Calibration Uncertainty: ±0.25% in all ranges
- Power: 100, 120, 220, or 240 Vac +5% -10%, 48 - 440 Hz, less than 10VA
Keysight U2054XA USB Average Power Sensor
- Frequency range of 10 MHz – 40 GHz
- USB connectivity with wide dynamic range of -70 to +20 dBm
- Fast real-time measurement
Rohde & Schwarz NRP6A
- Measurement range: -70 dBm to +23 dBm
- Frequency range: 8 kHz to 6 GHz
- N connector
Keysight N8487A Thermocouple Power Sensor
- EEPROM to store cal factors eliminates manual entry
- Wide frequency range from 50 MHz to 50 GHz
- Wide dynamic range from -35 dBm to +20 dBm
Gigatronics 80324A High Power Sensor
Keysight 8482B Power Sensor
- Excellent SWR for reducing mismatch uncertainty
- Accurate calibration and traceability to US National Institute of Standards and Technology (NIST)
- Compatible with EPM, EPM-P and P-series power meters, plus the E1416A VXI and discontinued 70100A and 43X power meter
Gigatronics 80701A Modulated Power Sensor
Gigatronics 16934A Low Frequency Power Sensor
Keysight U2022XA
- Frequency range of 50 MHz to 40 GHz
- Wide dynamic range of -30 to +20 dBm (peak/gated), -45 dBm to 20 dBm (average only mode)
- 30 MHz video bandwidth
Bird 4421 Multifunction Power Meter
- ±1% Accuracy - Accomplished through the use of sensors with an automatic frequency compensation scheme, where the error contributions due to directional coupler frequency response
- Wide Dynamic Range - The instrument will meet the full accuracy specification over a 35 dB dynamic range
- Excellent Measurement Repeatability - Typically <0.1%
Giga-tronics 8651A Single Channel Power Meter
Keysight E9304A E-Series Average Power Sensor
- Measure transmitter power and receiver sensitivity at Very Low Frequency (VLF) to microwave frequencies...
- High maximum power specification
- Low SWR for reducing mismatch uncertainty
Rohde & Schwarz NRP-Z22 Three-Path Diode Power Sensor
- Measurement range: -57 dBm to +33 dBm (2 nW to 2 W)
- Frequency range: 10 MHz to 18 GHz
- N connector
Keysight 8487A Power Sensor
- Frequency range 50 MHz to 50 GHz
- Accurate average power measurements over -30 to +20 dBm
- Thermocouple power sensing element
