Anritsu Field Master Pro MS2090A
The Anritsu Field Master Pro MS2090A is a device used for interference hunting and in-depth signal analysis. The MS2090A has advanced measurement accuracy, USB and Ethernet interfaces, and a modulation bandwidth of 100 MHz. With a frequency range of from 9 kHz to 9/14/20/26.5/32/43.5/54 GHz, the device covers a variety of testing requirements and has efficient testing applications. The unit has a 10.1 inch, 1280 x 800 color touchscreen display, a 2+ hour battery life, a typical amplitude accuracy of ±0.5 dB.
The built-in real-time spectrum analyzer (RTSA) uses dependable technology, making the Anritsu MS2090A an ideal choice for technicians looking for a reliable interference capturing tool. This user-friendly and accurate spectrum analyzer can help with the completion of transmitter analysis, satellite system monitoring, and more. The high-performance tool can locate interferences and allow the technician to maintain the quality of the systems in question. The Anritsu MS2090A successfully works with a 5G network’s technology.
Reach out to an ATEC rental agent today to learn more about the Anritsu Field Master Pro MS2090A and other Anritsu products. We can also offer expertise in what product to choose for your specific testing requirements and standards.
| Frequency Range | 9 kHz to 9/14/20/26.5/32/43.5/54 GHz |
| Analysis Bandwidth | 100 MHz |
| Demodulation | 5G NR demodulation, RF and modulation quality plus SSB signal analysis |
| TOI | +20 dBm |
| DANL (with pre amp) | –164 dBm |
| Phase noise @ 1 GHz | -110 dBc/Hz @ 100 kHz offset (typical) |
| RBW/VBW | 1 Hz to 10 MHz |
| Input SWR | 1.5 |
| Amplitude Accuracy | <14 GHz ±1.3 dB (±0.5 dB typical) |
| RTSA bandwidth | 22 MHz, 55 MHz, 110 MHz (option dependent) |
- 10.1 inch, 1280 x 800 color touchscreen display
- Gated sweep for timed gated spectrum measurements
- Complex limit lines with pass/fail
- IQ capture and export of 5G waveforms
- USB 3.0 and Ethernet Interfaces
- 2+ hours battery life
- Interference hunting and spectrum clearing networks
- Broadcast transmitter analysis
- Microwave radio links
- Satellite system monitoring
