| Insert dimensions |
Outer diameter: 29.8 mm (1.17 in)
Inner diameter: 25.6 mm (1.01 in)
Length: 210 mm (8.27 in) |
| Weight |
1060 g (37.3 oz) |
| Temperature range |
@ ambient temp. 0°C /32°F: 10 to 700°C/32 to 1292°F
@ ambient temp. 23°C /73°F: 33 to 700°C/91 to 1292°F
@ ambient temp. 40°C /104°F: 50 to 700°C/122 to 1292°F |
| Stability |
@ 33 to 125°C/91 to 257°F: ± 0.008°C/± 0.015°F
@ 125 to 425°C/257 to 797°F: ± 0.015°C/± 0.027°F
@ 425 to 700°C/797 to 1292°F: ± 0.02°C/± 0.036°F |
| Heating time |
33 to 700°C /91 to 1292°F: 45 minutes |
| Cooling time |
700 to 100°C / 1292 to 212°F: 43 minutes
100 to 50°C / 212 to 122°F: 17 minutes
50 to 33°C / 122 to 91°F: 20 minutes |
| Resolution |
User selectable
All temperatures: 1° or 0.1° or 0.01° or 0.001° |
| Display |
Easy-to-read color VGA display |
| Inserts |
14 multi-hole metric inserts for sizes from 3 mm to 16 mm |
| Software |
JofraCal Calibration Software |
