AH Systems SAS-563P Passive Shielded Loop Antenna Rentals

1kHz - 30MHz

The AH Systems SAS-563P Passive Shielded Loop Antenna is designed to conduct shielding effectiveness tests, offering a 1kHz to 30MHz frequency range and an impedance of 50Ω. The antenna is protected from the electric component by its all-metal shield. This shield also ensures that it only produces and measures the magnetic component of the radiated energy.

AH Systems SAS-560 Passive Loop Antenna

Low Frequency Range of 20 Hz to 2 MHz
Individually Calibrated (Calibration included per IEEE-291)
Rugged Construction

Solar Electronics 9230-1 Radiating Loop | 30 Hz - 100 kHz

Frequency range of 30 Hz to 100 KHz
Radiating loop: 12 cm in diameter
Sensing loop (used for calibration): 4 cm in diameter

PMM RF-300 Large Loop Antenna System (LLAS)

Fully compliant with EN 55015 (CISPR-15)
9 kHz to 30 MHz calibrated frequency range
Complete 3 axis system with switching unit

Com-Power AL-130 Active Loop Antenna | 9 kHz - 30 MHz

Smooth Antenna Factor Curve
Battery Powered
Built in Preamplifier

Solar 7334-1 Loop Antenna | 30 Hz - 15 kHz

Loop antenna
Equipped with an epoxy-glass base plate
BNC connector

AH Systems SAS-564 12-Inch Transmit Loop | 1 kHz – 30 MHz

Broad Frequency Range of 1 kHz to 30 MHz
Radiated
Rugged Construction

EMCO/ETS-Lindgren 6509 Transmitting Loop Antenna | 1 kHz - 30 MHz

Type N female connector
Manually switchable four-band transformer
Individually calibrated in accordance with the IEEE-291 Section 2.3.1 methods

AH Systems AK-18G EMC Antenna & Probe Kit | 20 Hz - 18 GHz

Schwarzbeck HHS 5201-98

Rundes Helmholtz-Spulenpaar Circular Helmholtz Coils
Coil diameter of 84 mm
Fequency range of DC to 200 kHz

Fairchild ALP-10 Frequency Antenna, 20 Hz - 100 kHz

Schwarzbeck HFRA SF02G

10 kHz – 30 MHz frequency range
Tunable resonant magnetic loop antenna
To generate extremely high magnetic fields

ETS-Lindgren 7605/7606 Coil/Shielded Coil Antennas

ETS-Lindgren 6507 Active Shielded Loop | 1 kHz - 30 MHz

Narda IDA Directional Loop Antenna 1, 3100/11 | 20 MHz - 250 MHz

High measurement sensitivity
Directional characteristic largely independent of frequency
Mechanically robust

ETS-Lindgren 7604 Shielded Coil Antenna

Narda IDA Directional Shielded Loop Antenna, H-Field 3100/14 | 9 kHz to 30 MHz

High measurement sensitivity
Pronounced figure of eight directional characteristic, ideal for directional null direction finding
Mechanically robust

AH Systems SAS-563B Active Loop Antenna | 1 kHz to 30 MHz

Broad Frequency Range of 1 kHz to 30 MHz
Individually Calibrated (1 Meter calibration included)
FCC, MIL-STD, VDE and TEMPEST Testing

ARA PLA-130/A Untuned Loop Antenna | 1 kHz - 30 MHz

Both active and passive antennas to meet a wide range of testing requirements
Designed for the shield room testing requirements of MIL-STD 285 and NSA 65-6
Capable of handling 1 kW input power

Frequency range:	1kHz - 30MHz
Impedance:	50Ω (Nominal)
Shielding:	Electrostatic (Faraday) shield
Connector:	N, Female
Mounting base:	1/4 x 20 Thread, Female
Loop diameter:	12inches (30.5cm)
Weight:	2.0lbs (0.91kg)
